- Page 1 SE155-30 RECUMENT OWNER’S MANUAL PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR RECUMENT!
-
Page 2: Safety Hints
Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable ■ for use on your elliptical. Quality athletic shoes are recommended to avoid leg fatigue. SAVE THESE INSTRUCTIONS - THINK SAFETY! CAUTION!! Please be careful when un-packing the carton. SE155-30- TE002_ 1206A... -
Page 3: Assembly Pack Check List
Assembly Pack Check List STEP 1. #43- 5/16" × 3/4" Button #53- M5 × 12 mm Phillips Head Socket Bolt (13pcs) Head Screw (4pcs) #44- 5/16” Flat #46- 5/16" Split #45- 5/16" Curved Washer (1pc) Washer (8pcs) Washer (4pcs) STEP 2. #43- 5/16"... - Page 4 Assembly Pack Check List STEP 4. #46- 5/16" Split #91- 5/16" × 1" Button #44- 5/16” Flat Washer (2pcs) Head Socket Bolt (2pcs) Washer (2pcs) #29- 1/2" × 70mm #30- 1/2" Nyloc Carriage Bolt (2pcs) Nut (2pcs) #68- 19m/m Wrench (1pc) #67- Combination M5 Allen Wrench &...
- Page 5 Assembly Instructions STEP 1: Locate the Console Mast (9) and slide on Console Mast Cover (79). Make sure the cover is facing the correct direction, as shown below, before sliding onto mast. Install the wiring harness (90) into the bottom of the mast and out the top. Be careful when installing the console mast to the mainframe so as not to pinch or cut the wiring harness;...
- Page 6 STEP 2: Locate the Right Swing Arm (Upper) (8) and install it through the Swing Arm Bushing (23) and secure to the Lower swing arm (6). Use M5 Allen Wrench (67) to tighten 2pcs of 5/16” Button Head Socket Bolts (56) and 2pcs of 5/16" Nyloc Nuts (55) to the swing arm assembly.
- Page 7 STEP 3: Locate the Left Swing Arm (Upper) (7) and install it through the Swing Arm Bushing (23) and secure to the Lower swing arm (5). Use M5 Allen Wrench (67) to tighten 2pcs of 5/16” Button Head Socket Bolts (56) and 2pcs of 5/16" Nyloc Nuts (55) to the swing arm assembly.
- Page 8 STEP 4: 1. Locate the Pedal Axle Spacer (25) and Right side Pedal Arm Assembly (2) and install onto the pedal axle at the large rotating wheel at the rear of the elliptical. Use the M5 Allen Wrench (67) to tighten the 5/16” Button Head Socket Bolt (91), 5/16"...
-
Page 9: Function Buttons
Console FUNCTION BUTTONS MODE 1. Press Mode button to select hour, minute, year, month and date when batteries are installed. 2. Press the mode button to select TIME, DISTANCE, CALORIES or PULSE to preset a goal value. 3. Press the mode button during exercise to select which data will be displayed in large LCD window. -
Page 10: Lcd Functions
BODY FAT Press this button to enter Body Fat measure function then press MODE key to enter setup of your personal data of Gender, Age, Height and Weight. After completing data entry press it again to measure your Body fat ratio (FAT%) and BMI. RECOVERY Press to enter the heart rate recovery function. -
Page 11: Monitor Operation
TEMPERATURE Displays current room temperature from 10 ℃ to 60 ℃ when the monitor is in sleep mode. MONITOR OPERATION: Power on: Install two 1.5V UM-3 or AA batteries. The monitor will perform an LCD segment test indicated by a long beep sound. (Whenever batteries are removed, all the data values will be reset to zero or default value.) Setting the clock: Press the MODE and SET buttons to set the clock time, year, month, and day. - Page 12 Body Fat - 9-1. Press BODY FAT key to enter body fat measurement. 9-2. Press MODE and SET buttons to input your personal data. Each personal data setting is described as the following: AGE: 10 ~ 99 years HEIGHT: 100 ~ 250 cm (or 3’03” ~ 8’02“) WEIGHT: 10 ~ 200 kg (or 22 ~ 440 lb) 9-3.
