Weight Limit: 600 Lb / 272 Kg
C.W.-2021.3.5
2021 Dorel Home Products All Rights Reserved
C
Thank you for purchasing from Dorel!
DO NOT RETURN TO THE STORE !
I f parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
You can also chat with us at www.dhpfurniture.com
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
DA2047739 (Green Velvet),
DA2047539 (Blue Velvet),
DA2047039 (Gray Velvet)
Sofa
Lot Number
(TAKEN FROM CARTON)
B34DA2047039-010045
Advertisement
Table of Contents
Related Manuals for Dorel Home Products DA2047739
Summary of Contents for Dorel Home Products DA2047739
- Page 1 Visit www.dhpfurniture.com/eng/replacement-parts or call Toll-Free 1-800-267-1739 You can also chat with us at www.dhpfurniture.com Lot Number Date of Purchase (TAKEN FROM CARTON) THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY C.W.-2021.3.5 B34DA2047039-010045 2021 Dorel Home Products All Rights Reserved...
-
Page 2: Limited 1-Year Warranty
Limited 1 year Warranty Read Before Beginning Assembly ● Dorel warrants this product to be free from defects in material and Work in a spacious area and near where the unit will be used, preferably on a workmanship and agrees to remedy any such defect. This warranty covers carpet, or use a piece of the cardboard packaging to protect your floor and product. - Page 3 PARTS & & & &...
- Page 4 LEFT SEAT BOARD BOLT METAL PLATE INNER SEAT CUSHION PLASTIC WASHER SEAT COVER PILLOW COVER INNER PILLOW PART NUMBERS PART NUMBERS PART DA2047739 DA2047539 DA2047039 PART DA2047739 DA2047539 DA2047039 Each part has a unique part number. LABELS LABELS (Green Velvet）...
-
Page 5: Hardware List
Hardware Pack Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step DA2047739 (Green Velvet), instructions. DA2047539 (Blue Velvet), TDA2047039-00 The screw(s), bolt(s) to be used at each step are... - Page 6 Step 1 Attach legs K & plastic washers N to the armrests G and H by rotating clockwise.
- Page 7 Step 2 Attach right seat board I & left seat board ● J with metal plate M & bolts as shown.
- Page 8 Step 3 Attach right seat board I to right armrest G ● , and left seat board J to left with bolts ● armrest H with bolts as shown.
- Page 9 Step 4 Attach the right seat frame C & left seat frame D with front leg base A, rear leg base B & bolts ● as shown.
- Page 10 Step 5 Attach legs K & plastic washers N to the leg base A & B by rotating clockwise.
- Page 11 Step 6 Insert pre-assembled seat frame C & D into armrest G & H as shown.
- Page 12 Step 7 Attach front leg base A to pre-assembled ● seat board J & I with bolts as shown.
- Page 13 Step 8 Insert left backrest F into right backrest E, then raise the fabric flap on the back of backrests F & E. Open the zipper and attach the backrests F & E with bolts L, 呻 then close the zipper.
- Page 14 Step 9 Open the zipper on the back of pre- assembled backrests F & E, attach them to the armrests H & G with bolts L as shown, then close the zipper and place the fabric flap into position using the velcro strips.
- Page 15 Step 10 Carefully cut the plastic bag using scissors and remove the inner pillow R. Then insert the inner pillow R into pillow cover Q and close the zipper.
- Page 16 Step 11 Carefully cut the plastic bag using scissors and remove the inner seat cushion P. Then insert the inner seat cushion P into seat cover O and close the zipper.
- Page 17 Step 12 Q & R Q & R Put the pillows and seat cushions onto the sofa as shown. O & P O & P...
-
Page 18: Helpful Hints
Helpful Hints CAUTION: This unit is intended for use only with the products and/or maximum Move your new furniture carefully, with two people weights indicated. Use with other products and/or products heavier than the • lifting and carrying the unit to its new location. maximum weights indicated may result in instability or cause possible injury. -
Page 19: Información Sobre La Garantía
¡NO LO REGRESE A LA TIENDA! DA2047739 (Terciopelo Verde), Si le faltan piezas o las que se incluyen están dañadas, con DA2047539 (Terciopelo Azul), mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. DA2047039 (Terciopelo Gris) Visite www.dhpfurniture.com/spa/support-home Sofá... -
Page 20: Part Numbers
Paso 1 Como se muestra (sección en inglés) une K y N a G y PART NUMBERS H girando en el sentido de las agujas del reloj. ETIQUE DA2047039 DA2047739 DA2047539 TAS DE DESCRIPCIÓN (Terciopelo Verde) (Terciopelo Azul) (Terciopelo Gris) -
Page 21: Consejos Útiles
Límites de peso: 600 Lb / 272 Kg Paso 7 Une A al ensamblaje (J e I) con (2). Consejos útiles Paso 8 Inserte F en E, luego levante la solapa de tela en la parte ● Mueva sus muebles nuevos con cuidado, se requiere de dos personas para posterior de (F &... -
Page 22: Informations Sur La Garantie
NE PAS RETOURNER CE PRODUIT AU DA2047739 (Velours Vert), MAGASIN ! DA2047539 (Velours Bleu), Si une pièce est manquante ou endommagée, nous vous expédierons avec plaisir vos pièces de remplacement DA2047039 (Velours Gris) gratuitement. Canapé Visitez www.dhpfurniture.com/fre/support-home ou appelez au 1-800-267-1739 CE FEUILLET CONTIENT DES INFORMATIONS DE SÉCURITÉ... -
Page 23: Liste Des Pièces
Pièces Quincaillerie Pour des pièces de rechange, visitez DA2047739 (Velours Vert), www.dhpfurniture.com/fre/replacement-parts DA2047539 (Velours Bleu), TDA2047039-00 DA2047039 (Velours Gris) IMPORTANT: La liste des références ci-dessous est propre à votre produit. Veuillez l'avoir sous la main lorsque vous appelez pour des pièces de rechange. -
Page 24: Conseils Utiles
Limite de Poids: 600 Lb/ 272 Kg Étape 7 Joindre A à l'assemblage (J et I) avec (2). Conseils utiles Étape 8 ● Déplacez votre nouveau mobilier avec soin, nous recommandons deux Insérez F dans E, puis remontez le rabat en tissu à l'arrière des (F personnes pour soulever et transporter le mobilier vers son nouvel emplacement.
