Weight Limit:250Lb/113Kg
C.W.-2020. 7 .1
DA2011329N (Light Gray)
Thank you for purchasing from Dorel !
DO NOT RETURN TO THE STORE !
I f parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
Accent Chair
DA2011229N (Mustard)
Lot Number
B34DA2011000N-010045-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Accent DA2011329N and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Home Products Accent DA2011329N

Summary of Contents for Dorel Home Products Accent DA2011329N

  • Page 1 Accent Chair DA2011329N (Light Gray) DA2011229N (Mustard) Weight Limit:250Lb/113Kg Thank you for purchasing from Dorel ! DO NOT RETURN TO THE STORE ! I f parts are missing or damaged, we will gladly ship your replacement parts free of charge. Visit www.dhpfurniture.com/eng/support-home or call Toll-Free 1-800-267-1739 Date of Purchase...
  • Page 2 Limited 1 year Warranty Read Before Beginning Assembly Dorel warrants this product to be free from defects in material and workmanship ● Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product.

  • Page 3: Parts List

    PARTS LIST...

  • Page 4: Part Numbers

    PART S LIST Seat Cushion Left Side Frame Right Side Frame Round Bar Backrest upper frame X 1 PCS X 1 PCS X 1 PCS X 1 PCS X 2PCS IMPORTANT: Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts.

  • Page 5: Hardware List

    HARDWA RE LIST BOLT BOLT ALLEN KEY 1/4"*1-5/8" 1/4"*3/4" 1 PC 2 PCS 7 PCS Please do not completely tighten all the hardware, until the entire assembly is complete, unless Hardware Pack otherwise indicated in the step-by-step instructions. The screw(s), bolt(s) to be used at each step are Hardware Pack #: TDA2011329N-00 shown in actual size in the lower right corner of the page.
  • Page 6 Step 1 Put Right Side Frame (A) on the ground, insert one extremity of each Round Bar (C) into the Right Side Frame (A). Then insert the other extremity of the round bar (C) into the Left Side Frame (B) as shown. Please make sure that the bracket of the Round Bar (C) is in the same direction as the other brackets located on the Side...
  • Page 7 Step 2 Insert the Backrest Upper Frame (D) on Side Please make sure the bracket of Frames（A&B）as shown. the Backrest Upper Frame (D) If needed, you can use a hammer to facilitate faces forward. this step. Use the hammer gently, in order to prevent damage of the components.
  • Page 8 Step 3 Attach the Seat Cushion (E) to the pre-assembled metal frame with bolts as shown.
  • Page 9 Step 4 Attach the Back Cushion (F) to the pre-assembled metal frame with bolts as shown.
  • Page 10 Step 5 Attach the Back Cushion (F) to the pre-assembled metal frame with bolts as shown.

  • Page 11: Helpful Hints

    Helpful Hints CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ● Move your new furniture carefully, with two people Keep away from heat to avoid glazing, melting or burning of components.
  • Page 12 Silla de Acento ¡NO LO REGRESE A LA TIENDA! Si le faltan piezas o las que se incluyen están dañadas, con DA2011329N (Gris claro) mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. DA2011229N (Mostaza) Visite www.dhpfurniture.com/spa/support-home o llame gratis al 1-800-267-1739 ESTE INSTRUCTIVO CONTIENE INFORMACION IMPORTANTE DE SEGURIDAD.

  • Page 13: Consejos Útiles

    Partes Límites de peso: 250Lb/113Kg Instruciones Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home Etapa 1 Coloque (A) en el piso e inserte una extremidad de cada (C) en (A). Luego Todo se incluye en 1 caja(s) grande(s)! inserte la otra extremidad de (C) en (B) como se muestra (sección en inglés). NOTA: Asegúrese de que los soportes en (C) estén en la misma dirección Antes de deshacerse de las cajas de cartón, asegúrese de que estén vacías.

  • Page 14: Informations Sur La Garantie

    Fauteuil d'appoint NE PAS RETOURNER CE PRODUIT AU MAGASIN ! Si une pièce est manquante ou endommagée, nous vous DA2011329N (Gris Clair) expédierons avec plaisir vos pièces de remplacement gratuitement. DA2011229N (Moutarde) Visitez www.dhpfurniture.com/fre/ support-home ou appelez au 1-800-267-1739 Date d'achat Numero de lot CE FEUILLET CONTIENT DES INFORMATIONS DE SÉCURITÉ...

  • Page 15: Conseils Utiles

    Pièces Limite de Poids: 250Lb/113Kg Instructions Pour des pièces de rechange, visitez www.dhpfurniture.com/fre/support-home Etape 1 Placer (A) sur le sol et insérer une extrémité de chaque (C) dans (A). IMPORTANT: La liste des références ci-dessous est propre à votre produit. Ensuite insérer l'autre extrémité...
