Dorel Home Products DA2023169 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Dorel Home Products Manuals
  4. Indoor Furnishing
  5. DA2023169
  6. Assembly instructions manual

Dorel Home Products DA2023169 Assembly Instructions Manual

2 seater sofa
Hide thumbs Also See for DA2023169:
Table of Contents

Advertisement

Quick Links

Download this manual
Weight Limit: 400Lb / 102 Kg
A.N. - 2020/7/16
© 2014 Dorel Home Products All Rights Reserved
DA2023169 (BLACK), DA2023269 (GRAY)
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly shipyour
replacement parts free ofcharge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
2 SEATER SOFA
Lot Number
(TAKEN FROM CARTON)
B34DA202326900
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA2023169 and is the answer not in the manual?

Questions and answers

Dexter
June 9, 2025

My warranty is finish but I need part e and f the wings for model da2023279

0

Related Manuals for Dorel Home Products DA2023169

Summary of Contents for Dorel Home Products DA2023169

  • Page 1 Visit www.dhpfurniture.com/eng/replacement-parts or call Toll-Free 1-800-267-1739 Date of Purchase Lot Number (TAKEN FROM CARTON) THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. A.N. - 2020/7/16 B34DA202326900 © 2014 Dorel Home Products All Rights Reserved...

  • Page 2: Limited 1-Year Warranty

    Limited 1 year Warranty Read Before Beginning Assembly ● DHP warrants this product to be free from defects in material and workmanship Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product.
  • Page 3 PARTS...

  • Page 4: Parts List

    Each part has unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. • Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above! PART DA2023169 DA2023269 LABELS (Black)

  • Page 5: Hardware List

    HARDWARE LIST Plastic Washer M10 Hardware Pack Please do not completely tighten all the hardware, until the entire assembly is complete, unless Hardware Pack : TDA2023169-00 otherwise indicated in the step-by-step instructions. The screw(s), bolt(s) to be used at each step are shown in actual size in the lower right corner ofthe page.
  • Page 6 Step 1 Carefully unpack parts/hardware from storage of seat body and place on a clean flat surface.
  • Page 7 Step 2 Place both arms (B), (C) as shown below, secure two legs (G) and plastic washer (1) into pre-drilled holes on the bottom of arms. Please do not overtighten.
  • Page 8 Step 3 Carefully lift and turn assembled arms (B), (C) onto its legs. Attach seat (A) to right arm (B) and left arm (C) by inserting the metal brackets on seat (E) into the metal glides on right arm (B) and left arm (C) as shown below.
  • Page 9 Step 4 Insert both backrest wing (E), (F) metal plates to both sides of back (D). Ensure it is correctly placed.
  • Page 10 Step 5 Insert backrest with ear piece metal plates to both arms as shown below. Ensure it is correctly placed.
  • Page 11 Step 6 Stretch and pull down rear cover evenly before securing velcro strip to seat base. Repeat if necessary for better fit.

  • Page 12: Helpful Hints

    Helpful Hints CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. • Move your new furniture carefully, with two people lifting and carrying the unit to its new location.
  • Page 13 DA2023169 (Negro), DA2023269(Gris) ¡NO LO REGRESE A LATIENDA! Si le faltan piezas o las que se incluyen están dañadas,con mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. www.dhpfurniture.com/spa/replacement-parts Visite SOFÁ 2 PLAZAS llame gratis al 1-800-267-1739 Fecha de compra Nú...
  • Page 14 NÚ MERO DE PIEZA DA2023169 DA2023269 ETIQUETAS DE PIEZAS (Negro) (Gris) T628750 T628820...

  • Page 15: Consejos Útiles

    Lí mites de peso: 400 Lb Instrucciones Paso 1 Consejos ú tiles Desembale cuidadosamente las piezas / hardware del almacenamiento del cuerpo del asiento y colóquelo en una superficie limpia y plana.  Su futón puede cambiar de posición de sofá a la posición d e cama.
  • Page 16 DA2023169 (Noir), DA2023269 (Gris) NE PAS RETOURNER CE PRODUIT AU MAGASIN ! Si une pièce est manquante ou endommagée, nous vous expédierons avec plaisir vos pièces de remplacement gratuitement. Visitez www.dhpfurniture.com/fre/replacement-parts CANAPÉ 2 PLACES ou appelez au 1-800-267-1739 Numero de lot Date d'achat CE FEUILLET CONTIENT DES INFORMATIONS DE SÉ...

  • Page 17: Liste Des Pièces

    Pièces Quincaillerie Pour des pièces de rechange, visitez www.dhpfurniture.com/fre/ # de paquet :TDA2023169-00 replacement-parts Remarque: Sauf indication contraire dans les instructions, ne IMPORTANT: La liste des références ci-dessous est propre à votre pas resserrer complètement les vis et les boulons, jusqu'à ce produit.

  • Page 18: Conseils Utiles

    Limite de Poids: 400 Lb Instructions É tape 1 Conseils utiles Déballez soigneusement les pièces / accessoires de rangement du  Votre futon peut être transformé entre Sofa & Lit. corps du siège et placez-les sur une surface plane et propre. ...
