Installing the Device
2.5 Connecting Power
3.
4.
10
[Optional] If connecting a second redundant power source, repeat
Step
2, making sure to connect the power supply to the P2 ports.
2
2
1
3
1
Positive Terminal
1
Negative Terminal
2
GND Terminal
3
Chassis Ground Terminal
4
Figure 2.5
Terminal Block Wiring – Dual DC Power Supply Inputs
Connect the chassis ground terminal to protective Earth.
Step 1
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06
and
4
