Setup Guide
Meraki Wall Plug
2. Secure your unit.
US Plug
EU Plug
Wall screws and anchors (not included)
Recommended size for wall screws:
Diameter
Length
US
#6
1inch
EU
M3
25mm
Welcome.
Here is your Meraki Wall Plug.
Meraki Wall Plug
Faceplate screw, bracket & bracket screw
Ethernet cable is not included.
You may also need wall screws and anchors for a secure mount.
Get started.
1. Plug it in.
US Plug
2
3. Create a gateway.
A gateway is a Meraki repeater connected to the Internet.
Every Meraki network must have one or more gateways.
Ethernet cable
4. Deploy your repeaters.
Your Meraki Wall Plug has a range of about 150 feet (50 meters).
When installing a new Meraki Wall Plug as a repeater, you can check its
connection to the rest of the network using the signal strength LEDs.
Check signal strength using LEDs.
Signal strength
1 light:
Fair
4 lights: Strongest
(US)
Meraki Wall Plug
2 brackets & 2 bracket screws
EU Plug
Router or modem
Flashing:
Weak signal
1
(EU)
3
Moving lights:
Searching for signal
Advertisement
Table of Contents
Related Manuals for Meraki Wall Plug
Summary of Contents for Meraki Wall Plug
- Page 1 4. Deploy your repeaters. Your Meraki Wall Plug has a range of about 150 feet (50 meters). When installing a new Meraki Wall Plug as a repeater, you can check its connection to the rest of the network using the signal strength LEDs.
- Page 2 If this is your first time on Dashboard, create a new account. Congratulations. Register all of your repeaters. You will need your Meraki Order Number (found on your invoice) or You’re done! the MAC address and serial number of each repeater (found on the back of each unit).
