Jedmed Combo 50 Handy Manual

AFHCAN
www.afhcan.org
The JedMed Otoscope
1. Stand by light and
power button
2. WB—White balance
3. WND—Window Size
4. Boost—Brightness
5. Camera input
6. Light output
7. Main power supply
8. Main (external) fuse draw
9. Power cord
10. Video outputs
Cooling fan
11.
Operating the JedMed Otoscope
1. The Otoscope can have the
main power switch left on
when not in use.
3. White Balance: To be performed once a week, or when the image color appears off. Used to ensure accurate
color reproduction.
To perform a white balance:
HG-0269 JedMed Otoscope
Handy
Guide
1
11
DO NOT BLOCK THE COOLING FAN
1. Aim the otoscope tip at a uniformly illuminated white sheet of paper.
2. While aiming, push and release the white balance button.
3. Monitor will beep once, the white balance is complete.
Copyright © 2015 Alaska Native Tribal Health Consortium. All rights reserved.
JedMed Otoscope LED Combo 50
2 3 4
10
2. Turn on the video
otoscope light source
by pressing the
yellow POWER
button. When the
power is on, the LEDs
on the front panel
will flash and then
turn green.
5 6
7
8
9
1
