Proscend 708EP-AC Quick Installation Manual

708EP-AC 8-Port PoE Long Reach
Switch/Extender
Quick Installation Guide
Overview
The 708EP-AC PoE Switch/Extender features 8 pairs of Long Reach
Ethernet connections in cooperation with the 101EPI. Each pair carries
Ethernet traffic and power over an Ethernet cable up to 800 meters. The
708EP-AC is designed to locate at network side where the 101EPI is
located at the remote side.
LED Indicators
Each LED indicator on the front panel is described in the following table.
LED Color
PWR Green
SYS Green
PoE1~8 Green
Green
UPLINK
Yellow
Green
LINE 1~8
Yellow
LINE Port Pin Assignment
8-pin RJ45
The LINE interfaces of the 708EP-AC are standard 8-pin
RJ45 connectors. The following tables display the pinouts.
1 8
MDI Port Pinouts
Pin Description
1 TX+
2 TX-
3 RX+
4 Not used
5 Not used
6 RX-
7 Not used
8 Not used
Proscend Communications Inc. All rights reserved.
LED
Description
On Device Power On.
Off Device Power Off.
On
System is working.
Off System is off.
Blinking Device Error.
On
Powered Device Connected.
Off Powered Device Disconnected.
On 1000Mbps UPLINK LINK UP.
Off
1000Mbps UPLINK LINK DOWN.
Blinking 1000Mbps Data Transmitting.
On 100/10Mbps UPLINK LINK UP.
Off
100/10Mbps UPLINK LINK DOWN.
Blinking 100/10Mbps Data Transmitting.
On 100Mbps LINE LINK UP.
Off LINE LINK DOWN.
Blinking 100Mbps Data Transmitting.
On 10Mbps LINE LINK UP.
Off LINE LINK DOWN.
Blinking 10Mbps Data Transmitting.
MDI-X Port Pinouts
Pin Description
1 RX+
2 RX-
3 TX+
4 Not used
5 Not used
6 TX-
7 Not used
8 Not used
The PoE pinouts of the LINE interfaces are as below when 8 wires are
connected.
Version: 1.00
Pin
1
2
3
4
The PoE pinouts of the LINE interfaces are as below when 4 wires are
connected.
Pin
1
2
3
4
Connecting Power
Use the included power cord to connect the power socket on the front panel
to a power outlet.
Ground Connection
To prevent the effects of noise from electromagnetic interference (EMI), run
the ground connection from the ground screw to the grounding surface
before connecting the devices.
Reset Button
Reset button allows you to reboot the unit or restore to factory default
setting.
Reboot
Restore to factory default setting
- 1 -
PoE Pinouts
Description Pin
V+ 5
V+ 6
V- 7
V+ 8
PoE Pinouts
Description Pin
V+ 5
V+ 6
V- 7
Not used 8
Function
Press the button for 1 second
Press the button for more than 5 seconds
Description
V+
V-
V-
V-
Description
Not used
V-
Not used
Not used
Operation
