- Page 1 708E Series 8 Port PoE Long Reach Switch / Extender User Manual Version 1.00...
-
Page 2: Table Of Contents
Config / Interface of Device Setting ............... 14 6.2.4 Config/Port ......................15 6.2.5 User ........................18 6.2.6 Ping........................18 6.2.7 Load Default ......................19 6.2.8 Upgrade ........................ 19 6.2.9 Reboot ........................21 6.2.10 Logout ....................... 21 Precautions and Safety Warnings .................. 22 708E Series User Manual... -
Page 3: Introduction
The 708EPI-DC and 708EP-AC Long Reach Switches / Extenders feature 8 pairs of Long Reach Ethernet solutions with the companion the Ethernet Extender 101EPI remote devices connecting to each port of the 708E Series. Each solution pair carries Ethernet traffic and power over Ethernet cable up to 800 meters. -
Page 4: Specifications
RoHS (Pb fee) and REACH compliant Dimensions (W x H x D): 404 x 44.5 x 177 mm MTBF: > 25 years (708EPI-DC) Weight: 2.34 kg >22 years (708EP-AC) Rack Mounting 708E Series User Manual... - Page 5 400 meters 100Mbps 14.0 500 meters 100Mbps 22.0 500 meters 100Mbps 11.0 600 meters 10Mbps 19.5 600 meters 10Mbps 700 meters 10Mbps 16.5 700 meters 10Mbps 800 meters 800 meters 10Mbps 14.0 10Mbps 900 meters 900 meters 708E Series User Manual...
- Page 6 Dimensions Ordering Information Description Model Name 708EPI-DC 8-Port PoE Long Reach Switch/Extender, DC power input 708EP-AC 8 Port PoE Long Reach Switch/Extender, AC power input NOTE: Features and specifications are subject to change without prior notice. 708E Series User Manual...
-
Page 7: Hardware Description
Hardware Description 2.1 Line Port Pin Assignment The LINE interfaces of the 708E Series are standard 8-pin RJ45 connectors. The following tables display the pinouts. MDI Port Pinouts MDI-X Port Pinouts Description Description Not used Not used Not used Not used... -
Page 8: Din-Rail Mounting
NOTE: These screws are not included in the package. The head of each screw is less than 7 mm in diameter, the shaft is less than 3 mm in diameter, and the length is less than 10 mm in diameter. 708E Series User Manual... -
Page 9: Rack Mounting
STEP 2: After attaching two brackets, line up the rack-mounting positions of the holes in the brackets with the appropriate holes on the rack and then fasten the Switch on the rack by using screws NOTE: The rack mounting screws are not inclouded in the package. 708E Series User Manual... -
Page 10: Led Definition
100/10Mbps UPLINK LINK UP. Yellow 100/10Mbps UPLINK LINK DOWN. Blinking 100/10Mbps Data Transmitting. 100Mbps LINE LINK UP. Green LINE LINK DOWN. Blinking 100Mbps Data Transmitting. LINE 1~8 10Mbps LINE LINK UP. Yellow LINE LINK DOWN. Blinking 10Mbps Data Transmitting. 708E Series User Manual... -
Page 11: Power Connection
Use the included power cord to connect the power socket on the front panel to a power outlet. Ground Connecting To prevent the effects of noise from electromagnetic interference (EMI), run the ground connection from the ground screw to the grounding surface before connecting the devices. 708E Series User Manual... -
Page 12: Web Management
For the system security, changing the default password is strongly suggested after configuration. You can go to the User setting to reset. NOTE: • The device only supports one web session. • The timeout of web session is 15 minutes. 708E Series User Manual... -
Page 13: Web Interface
6.2 Web Interface 6.2.1 Information The system information is shown as below. (1) System shows Model Name, Hardware MCSV, Software MCSV, Software Version, PSE Software Version, MAC Address, Serial Number and System Up Time. 708E Series User Manual... -
Page 14: Status Of Interface Status
(1) The setting of Refresh Interval allows you to set up how long the information status is updated. (2) The Switch Port Status includes Broadcast/ Multicast / Unicast status and Link Status information by each port. Users can view the statistics of the port Receive packets and Transmit Packets through this page. 708E Series User Manual... - Page 15 0–5 0.44–12.94 15.4 unimplemented Very Low Optional 8–13 0.44–3.84 power Optional 16–21 3.84–6.49 Low power Optional 25–31 6.49–12.95 15.4 Mid power Valid for Type 2 35–45 12.95–25.50 High power (802.3at) devices, not allowed for 802.3af devices 708E Series User Manual...
-
Page 16: Config / Interface Of Device Setting
(1) LAN Setting can set up DHCP Client Mode, IP Address, IP Netmask, Gateway Address, DNS Primary, and DNS Secondary. Device can obtain IP/ Netmask / Gateway/ DNS from DHCP server if you are enabled “DHCP Client Mode”. The related information will show on ‘Status’ page as follows. 708E Series User Manual... -
Page 17: Config/Port
This section includes Line / LFPT and LAN Speed Setting. (1) Line Port: It allows you to select Line port Enable or Disable by each port. If you are disabled the Line port it unable to provide power to PD and establish connectivity. 708E Series User Manual... - Page 18 400 meters 100Mbps 14.0 500 meters 100Mbps 22.0 500 meters 100Mbps 11.0 600 meters 10Mbps 19.5 600 meters 10Mbps 700 meters 10Mbps 16.5 700 meters 10Mbps 800 meters 10Mbps 14.0 800 meters 10Mbps 900 meters 900 meters 708E Series User Manual...
- Page 19 It allows you to select LFPT Enable or Disable and has been further enhanced for monitoring and maintenance purposes. Link Fault Pass Through on the 708E Series can be enabled/disabled via WEB configuration and the 101EPI can be enabled/disabled via DIP switch on the device individually, and has been further enhanced for monitoring and maintenance purposes.
-
Page 20: User
Normal: user can setup and read anything, but Admin session Guest: user only can read status NOTE: Username and password can accept a maximum length of 31 characters. 6.2.6 Ping The Ping Setting is shown in the interface as below. 708E Series User Manual... -
Page 21: Load Default
Ethernet. You can update the new firmware via TFTP upgrade tools. For upgrade the firmware, you must have the new firmware file named *.*-upg.bin which will be supported by the supplier but you must have your own TFTP server. TFTP FW Upgrade Topology 708E Series User Manual... - Page 22 708E Series User Manual...
-
Page 23: Reboot
After clicking Reboot item, it will be shown the interface as below to make sure if you are ready to reboot or not. 6.2.10 Logout Logout the device. After clicking Logout item, it will be shown the interface as below to make sure if you are ready to Logout or not. 708E Series User Manual... -
Page 24: Precautions And Safety Warnings
This equipment relies on the building’s installation for short-circuit (overcurrent) protection. ● Ensure that a fuse or circuit breaker no larger than 3.5A is used. Hot parts! Burned fingers when handing the parts. ● Wait one-half hour after switching off before handing parts. ● 708E Series User Manual...
