  • Page 1 RA3100 File Converter Instruction Manual 1WMPD4004500...
  • Page 2 CAUTION (1) Turn off the power when the operation is abnormal. If it is impossible to trace the causes of an abnormal operation, please contact our sales representative. (2) The contents of this manual are subject to change without notice. (3) This manual is copyrighted with all rights reserved.

  • Page 3: Introduction

    Introduction Introduction "File Converter" is software for converting recorded data exported to external media from our data acquisition product OMNIACE RA3100 to a CSV or ASAM MDF (Ver. 4.1) file on a computer. RA3100 Symbols in This Manual Terms and symbols used in this manual denote as follows.

  • Page 4: Table Of Contents

    CONTENTS CONTENTS INTRODUCTION ..............................3 ..........................3 YMBOLS IN ANUAL CONTENTS ................................ 4 ENVIRONMENT ............................6 1.1........................6 YSTEM EQUIREMENTS 1.2........................6 NSTALLATION AND ETUP 1.2.1. Zip File ............................6 1.2.2. Extracting the Zip File ....................... 6 1.2.3. Installing the Microsoft Visual C++ Redistributable ..............
  • Page 5 CONTENTS 5.2.1. Conversion Data ........................39 5.2.2. cg_tx_acq_name (recording name) ..................39 5.2.3. cg_md_comment (comment on recording name) ..............40 5.2.4. cn_tx_name (name of X axis data) ..................40 5.2.5. cn_md_unit (unit name of X axis data) ................... 40 5.2.6. cn_sync_type (data type of X axis) ..................

  • Page 6: Environment

    1.Environment - 1.1.System Requirements 1. Environment This section describes the system requirements and installation procedure. 1.1. System Requirements Item Description Operating Windows 10 x86 (32-bit)/x64 (64-bit) English (Ver. 1507 or later) System .NET Framework 4.6 or later Intel Core i series Memory 4 GB (32-bit version)/8 GB or more (64-bit version) Display...
  • Page 7 1.Environment - 1.2.Installation and Setup The [Extract Compressed (Zipped) Folders] screen is displayed. Enter a path in the area indicated by the red box or click the [Browse] button to specify the destination. Click [Extract] to extract the file.

  • Page 8: Installing The Microsoft Visual C++ Redistributable

    1.Environment - 1.2.Installation and Setup 1.2.3. Installing the Microsoft Visual C++ Redistributable Double-click the "VC_redist.x86.exe" file. The exe file is included in the zip file. See "1.2.1 Zip File" and "1.2.2 Extracting the Zip File". Select [I agree to the license terms and conditions] and click the [Install] button. The program installation starts.

  • Page 9: Function

    2.Function - 2.1.Decimation Process 2. Function The software converts a recorded data file of the RA3100 (in dedicated binary format) into the CSV file (text) or ASAM MDF (Ver. 4.1) format. The conversion process is performed on multiple data files in multiple recording folders specified for a single conversion execution command.

  • Page 10: Date Range Sampling Process

    2.Function - 2.2.Date Range Sampling Process 2.2. Date Range Sampling Process The printer recording and SSD recording process of the RA3100 automatically divides recorded files into multiple files when recording is performed for an extended period of time, but a range can be specified as a start point and end point from the start of recording, even if the range spans over multiple files.
  • Page 11 2.Function - 2.2.Date Range Sampling Process MEMORY Recording For memory recording, a file is created for each block division. Start point (setting) End point (setting) Sampling range M1.bin M2.bin M199.bin M200.bin Regarding the sampling range when multiple recording folders of different recording times are specified The example below is for PRINTER, but the same applies for SSD and MEMORY.

  • Page 12: Data Merging Process

    2.Function - 2.3.Data Merging Process 2.3. Data Merging Process This function merges MEMORY recording with SSD recording or PRINTER recording into single channel of data. If only one of the recording files to merge exist, regular conversion (without data merging) is performed. The data is merged after the decimation process.

  • Page 13: Analog Channel (Normal/P-P) Data Merging

    2.Function - 2.3.Data Merging Process A sample of the analog data. (When the conversion range is 0 to 10 and SSD+MEMORY data merging is performed) The top waveform is the merged data after file conversion, the middle is the SSD recorded data, and the bottom is the MEMORY recorded data.

  • Page 14: Status (Trigger/Mark) Data Merging

    2.Function - 2.3.Data Merging Process 2.3.3. Status (Trigger/Mark) Data Merging MEMORY Trigger (output recording trigger of MEMORY Trigger Mark (trigger) Time Trigger recording) Mark Status data 1.01 Trigger 1.02 1.03 1.04 Trigger (output trigger 1.05 of MEMORY recording) 1.06 Mark -0.5 1.07 1.08...

  • Page 15: Usage Method

    3.Usage Method - 3.1.Flow of Operations 3. Usage Method 3.1. Flow of Operations Overview Reference Operation Copy the specified recording folder to USB memory or an "3.2. Copying Recorded Data SD memory card on the dedicated operation screen. from the RA3100 to USB Memory"...

  • Page 16: Ra3100 Main Unit

    3.Usage Method - 3.2.Copying Recorded Data from the RA3100 to USB Memory Recorded data list on internal SSD Recorded data list on external media Place a check mark (✔) on t he dat a t o back up Place a check mark (✔) i n t he sel ect i on f i el d of t he dat a t o back up and t ap t he 【Export】 key in the center to export the recorded data.

  • Page 17: Copying Recorded Data On Usb Memory To A Windows Computer

    3.Usage Method - 3.3.Copying Recorded Data on USB Memory to a Windows Computer 3.3. Copying Recorded Data on USB Memory to a Windows Computer Connect the USB memory or SD card copied to in "3.2. Copying Recorded Data from the RA3100 to Memory"...

  • Page 18: Starting The Software

    3.Usage Method - 3.4.Starting the Software 3.4. Starting the Software Double-click the "RA3100_File_Converter.exe" icon copied in "1.2. Installation and Setup". The [Main] screen is displayed. When a recording folder is not selected (when starting the software for the first time), the [There is no "Record" sub-folder in the selected folder.] dialog is displayed. Press the button.

  • Page 19: Configuring Settings And Executing File Conversion

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion 3.5. Configuring Settings and Executing File Conversion 3.5.1. Select Record Folder Button Press the Select Record Folder button to display the dialog for selecting a folder. Select the RA3100 folder, and press the button.

  • Page 20: Select All Button And Release All Button

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion 3.5.3. Select all button and Release all button Press the Select all button to select [Conv.] and the Release all button to deselect [Conv.]. 3.5.4. Recording List View and Recorded Data Conversion Settings Conv.
  • Page 21 3.Usage Method - 3.5.Configuring Settings and Executing File Conversion Number of recorded data Displays the number of points recorded for PRINTER/SSD/MEMORY. 0 indicates that the recording setup is OFF. Files The number of files (blocks) for MEMORY. The numerator indicates the number of recorded blocks and the denominator indicates the maximum number of recording blocks.

  • Page 22: Setup Button (Display [Setup] Screen)

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion 3.5.5. Setup button (display [Setup] screen) Press the Setup button to open the [Setup] screen. The item selected in the recording list on the [Main] screen is set in the [Recorded data name] combo box of the [Setup] screen. OK button Closes the [Setup] screen with the setting values retained.
  • Page 23 3.Usage Method - 3.5.Configuring Settings and Executing File Conversion Output file format Select CSV or MDF. MDF is ASAM MDF version 4.1. Max. number of output data per file Set the upper limit for the data (number of lines) to output to the CSV file. List separator / Decimal symbol Set the list separator and decimal symbol if the file is a CSV file.

  • Page 24: External Sampling Setup

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion PRINTER + MEMORY [data merge] check box Select to merge PRINTER data and MEMORY data. File conversion is not performed if the selected recorded data does not exist. "2.3. Data Merging Process".

  • Page 25: Conversion Button

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion OK button Closes the screen with the setting values retained. Cancel button Closes the screen with the setting values discarded. 3.5.7. Conversion button File conversion is performed by performing "2.2. Date Range Sampling Process"...

  • Page 26: Stop Button

    3.Usage Method - 3.5.Configuring Settings and Executing File Conversion In the example below, three items of recorded data are set for conversion. [Progress] screen Explorer After Conversion 3.5.8. Stop button Closes the [Main] screen. The last setting values are saved to the settings file. A separate settings file is saved for each Windows login user.

  • Page 27: Csv File Format

    4.CSV File Format - 4.1.Output Format 4. CSV File Format 4.1. Output Format CSV output is broadly divided into three category blocks. [Recorded Info] category Recorded information (fixed to 9 lines) [CH Info] category Channel information (fixed to 36 lines) [DATA] category Recorded data name (fixed to 1 line) Recorded data (number of lines equal to the sample count)

  • Page 28: Channel Information ([Ch Info] Category)

    4.CSV File Format - 4.3.Channel information ([CH Info] category) 4.3. Channel information ([CH Info] category) Fixed to 4 channels per slot and output fixed to an area with a total of 36 lines x 5 columns Format: "S1-CH1", type, signal name, ON/OFF, module (CH) specific information Column number Item name Column number Channel number...

  • Page 29: Module Specific Information

    4.CSV File Format - 4.3.Channel information ([CH Info] category) 4.3.1. Module specific information Product Output text number RA30-101 [Physical value conversion gain] [Physical value conversion offset] [Measurement range] [Coupling] [Low pass filter] [Antialiasing filter] Example: [GAIN=1] [OFFSET=0] [RANGE=500V] [COUPLING=DC] [L.P.F.=OFF] [A.A.F.=OFF] GAIN [physical value conversion] Physical value conversion factor OFFSET [physical value conversion]...
  • Page 30 4.CSV File Format - 4.3.Channel information ([CH Info] category) Product Output text number RA30-106 [Physical value conversion gain] [Physical value conversion offset] [Type] [Measurement range] [Data update] [Reference junction compensation] [LFD] Example: [GAIN=1] [OFFSET=0] [TYPE=K] [RANGE=HIGH] [UPDATE=NORMAL] [RJC=INT] [OpenDetect=OFF] GAIN [physical value conversion] Physical value conversion factor OFFSET [physical value conversion] TYPE [type]...

  • Page 31: Data Part ([Data] Category)

    4.CSV File Format - 4.4.Data part ([DATA] category) 4.4. Data part ([DATA] category) The data is structured with channels as columns and samples as lines. Two values (two columns) are output for each channel when Sampling Data Format (Normal/P-P) is "P-P" and one value (one column) is output for each channel when it is "Normal".

  • Page 32: Structure Of Data Output

    4.CSV File Format - 4.4.Data part ([DATA] category) 4.4.1. Structure of Data Output The output data count (data columns) differ according to the RA30-xxx module configuration, measurement enabled/disabled setting, recording device (PRINTER, SSD, or MEMORY), and sampling data format (Normal/P-P). "4.4.2.
  • Page 33 4.CSV File Format - 4.4.Data part ([DATA] category) Logic Channel Data [16ch] (Normal) The RA30-105 has channel groups A and B, with each group having 8 channels, for a total of 16 data items. The order of the 16 data items is indicated in the table below. Index Channel data A[1]...
  • Page 34 4.CSV File Format - 4.4.Data part ([DATA] category) The RA30-105 has channel groups A and B, with each group having 8 channels, for a total of 32 (2 x 16) data items. Level Level Level change change change Value 1 (Level) Value 2 (Flag) Input value Instantaneous value...

  • Page 35: Recorded Data Name (First Line)

    4.CSV File Format - 4.4.Data part ([DATA] category) 4.4.3. Recorded data name (first line) Output to the first line of the category with [DATA] as the signal name and unit name. The table below indicates example values for the signal name and unit name. Type Signal name Unit name...
  • Page 36 4.CSV File Format - 4.4.Data part ([DATA] category) Sampling Period Table Index Sampling period Sampling period unit Sampling speed 10 S/min 20 S/min 50 S/min 1 S/s [ms] 2 S/s [ms] 5 S/s [ms] 10 S/s [ms] 20 S/s [ms] 50 S/s [ms] 100 S/s...
  • Page 37 4.CSV File Format - 4.4.Data part ([DATA] category) Signal name set in RA3100 main unit The signal name set in [Channel list] - [Common] in the recording setup of the RA3100. It is blank when the signal name is not set. Physical quantity unit set in RA3100 main unit The unit set in [Channel list] - [Conversion] in the recording setup of the RA3100.

  • Page 38: Output Format Of Recorded Data

    4.CSV File Format - 4.4.Data part ([DATA] category) 4.4.4. Output Format of Recorded Data Time Data Format The time data in the first column is the result of multiplying the sample point Index by the sampling period "Sampling Period Table". With external sampling, it is the sample point. Output as an integer or fixed point with the start of the recording file as 0 (s, ms, us, or ns).

  • Page 39: Mdf File Format

    5.MDF File Format - 5.1.Characteristics 5. MDF File Format The format complies with ASAM MDF Version 4.1. Generally, only the format differs from CSV. This section is specific to MDF. "4. CSV File Format". 5.1. Characteristics Contains IDBLOCK, HDBLOCK, FHBLOCK, MDBLOCK, TXBLOCK, DGBLOCK, CGBLOCK, CNBLOCK, CCBLOCK, and DZBLOCK.
  • Page 40 5.MDF File Format - 5.2.Relationship between MDF and RA3100 Recorded Data 5.2.3. cg_md_comment (comment on recording name) The comment on the recording name is output to tx_data of the TXBLOCK referenced by cg_md_comment of the CGBLOCK. Format: A_B_C_D (see the table below for information on ABCD) Example) RecordingName_RA3100_SSD_Normal Symbol Description...
  • Page 41 5.MDF File Format - 5.2.Relationship between MDF and RA3100 Recorded Data 5.2.9. cn_md_comment (comment of channel data) The channel information is output to tx_data of the TXBLOCK referenced by cn_md_comment of the CNBLOCK. "Channel information ([CH Info] category)" ("4. CSV File Format").
  • Page 42 MEMO...
  • Page 43 File Converter RA3100 Instruction Manual 1WMPD4004500 1st Edition...
  • Page 44 A&D Company, Limited 3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013, JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-1566 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131, U.S.A. Telephone: [1] (408) 263-5333 Fax: [1] (408)263-0119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D AUSTRALASIA PTY LTD...
