A&D AD-8552EIP Instruction Manual

Ethernet/ip converter

Advertisement

Quick Links

A D - 8 5 5 2 E I P
A D - 8 5 5 2 E I P
E t h e r N t e
C o n v e r t e r
/
P
I
E t h e r N e t
/
P
C o n v e r t e r
I
1WMPD4004703

Advertisement

Table of Contents
loading

Summary of Contents for A&D AD-8552EIP

  • Page 1 A D - 8 5 5 2 E I P A D - 8 5 5 2 E I P E t h e r N t e C o n v e r t e r E t h e r N e t C o n v e r t e r 1WMPD4004703...
  • Page 2 This manual and Marks All safety messages are identified by the following, “WARNING” or “CAUTION”, of ANSI Z535.4 (American National Standard Institute: Product Safety Signs and Labels). The meanings are as follows: A potentially hazardous situation which, if not avoided, WARNING could result in death or serious injury.
  • Page 3 Contents 1. Introduction ................................. 4 1-1 Features ............................... 4 1-2 Cautions ............................... 5 2. Composition and Names ............................ 6 2-1 AD-8552EIP ..............................6 2-2 Accessories ..............................6 3. Specifications ..............................7 3-1 Dimensions ..............................7 3-2 Applicable models ............................8 4.
  • Page 4 ■When connected to an AD-4212C and AD-4212D, etc., it is possible to change the response speed, perform calibration with an external weight, and supply power from the weighing device. ■The hooks on the back of the AD-8552EIP allow one-touch mounting on a DIN rail. EtherNet/IP RS-232C AD-4212C, etc.
  • Page 5 1-2 Cautions Before use, confirm the following articles for safe operation. Grounding The Converter Be sure to ground this converter. Separate this earth ground line from others, like ground line of a motor, inverter or a power source. Unless the converter is grounded, it may result in receiving an electric shock, cause operation error or catch fire.
  • Page 6 2. Composition and Names 2-1 AD-8552EIP Front panel side Rear panel side LED(Status display part) RS-232C connector DIN rail hook Switch DIN rail groove Vent hole Vent hole Pull down when removing from DIN rail EtherNet/IP connector DC power connector...
  • Page 7: Specifications

    3. Specifications Voltage requirement : 24 VDC external power supply [+ 10%, -15%] Power requirement:9W Max (When power is supplied to 4 units such as AD-4212C) Communication interface : EtherNet/IP interface CT18 compliant (For connection with external devices) Refer to “5-1 EtherNet/IP specifications” :RS-232C interface (For connection to weighing device) Refer to “6-1 RS-232C specifications”...
  • Page 8 1.If the weighing device does not have an auto power-on function or auto-start function, it is necessary to turn on the display or each weighing device by key operation after turning on the power. ⋆ 2.The AD4212D has two types of RS-232C connectors. Connect the display connector and the RS-232C connector of AD-8552EIP. (Do not use the PLC connector.) ⋆...
  • Page 9: Power Supply Voltage

    4-1 Power-supply voltage Connect a constant voltage of external power supply (+ 10% -15%) within the range of 24 VDC to the DC power input terminal of the AD-8552EIP. Caution ●Do not use at a voltage exceeding the rated voltage range (24 VDC +10%-15%) ・Doing so may cause failure or heat generation.
  • Page 10: Ethernet/Ip Specifications

    MDI-X ⋆1 ⋆1 RD:Receive data(Input) TD:Send data(Output) Housing ⋆ 1.AD-8552EIP is compatible with Auto MDI-X / MDI. The LAN cable can be used either straight or cross. ■Communication specifications Communication standard EtherNet/IP (CT18 compliant) Vender ID 188:A&D Company Limited Device type 43 (0x2B):Generic Device...
  • Page 11: Connecting Cable

    Code ASCII *Factory setting 6-2 Connecting cable Connect with a cable applicable to the individual weighing device. Refer to “3-2. Applicable models”. ■Connection diagram (When connected to a weighing device.) Weighing AD-8552EIP(DTE) device (DCE) 1 1 (Vs) (Vs) (Va) (Va) Shield 1....
  • Page 12: Factory Setting

    ・Set the parameters required for communication using the AD-8552EIP switches (SW-1 to 5). Caution ・If the setting is changed, be sure to turn on the power off and on again of AD-8552EIP. When the power is turned on, the switch status is read and applied to operations.
  • Page 13 7-3 EtherNet/IP switching settings ■IP address setting The IP address allocation can be set within the following range by using the switch (SW-1, 2). [ 192.168.0.1 ] to [ 192.168.0.254 ], [ 192.168.1.10 ] (To set an IP address other than the above, refer to "10-4 Network setting screen".) SW-1 SW-2 IP address...
  • Page 14 7-4 RS-232C function settings ■Communication setting SW-3 CH1: RS-232C Baud Rate Setting state Setting state CH2: RS-232C Baud rate 2400 bps 2400 bps 9600 bps 9600 bps 19200 bps 19200 bps 38400 bps 38400 bps No.1, 2 No.3, 4 “1” “0”...
  • Page 15 ・ If the connected weighing device has a smart range function, the number of digits after the decimal point is automatically changed. If you want to fix the number of digits, use the fixed decimal point function. Example of storage format with fixed decimal point function(Example of CH1) AD-8552EIP internal data Weighing device Setting of decimal Weighing value...
  • Page 16 Status Green lit POWER Power on The AD-8552EIP is powered on. Error Red lit There is something wrong with the AD-8552EIP. The AD-8552EIP is not powered on. Green lit It is working normally. Green blink Not initialized. Module Status Red lit An unrecoverable failure has occurred.
  • Page 17 ⋆1.When changing the weight value to be used, refer to the instruction manual of the individual weighing device. 9-1 Preparing for communication 1. Set the following setting items so that the RS-232C of the weighing instrument and AD-8552EIP are the same. Reference: AD-4212C/AD-4212D factory setting...
  • Page 18 9-15 No function ※1.The AD-8552EIP outputs each command to the connected instrument when a "1" is written. ※2.The operation differs depending on the weighing device. For individual operation commands, refer to "3-2 Applicable model" or the instruction manual of the relevant weighing device.
  • Page 19 9-3 Input data (Instance100) The data transferred from AD-8552EIP to PLC, etc. is called Input data. Input data is used when acquiring data from the weighing device. ■Input data layout (T->O) [ Weighing device (CH1 to 4) -> AD8552EIP -> PLC , etc. ]...
  • Page 20 9-4 Detailed information of the Input data1 ■Weighing value [CH1 to 4 Weighing value] (CH1:byte 0 to 3, CH2:byte 18 to 21, CH3:byte 36 to 39、CH4:byte 54 to 57), Decimal point position [CH1 to 4 Decimal point position] (CH1: byte 6,7 CH2: byte 24,25, CH3: byte 42,43, CH4: byte 60,61) Example of weighing value and decimal point value by output of Weighing device (CH1)(When the decimal point position setting by SW-5 is AUTO)...
  • Page 21 9-5 Detailed information of the Input data2(Only for AD-4212C/AD- 4212D) The following items change only when connected to the AD-4212C / AD-4212D. When connected to other weighing devices, it will be the initial value. ■ Response characteristics [CH1 ~ 4 Response characteristics] (CH1:byte 10,11, CH2:byte 28,29, CH3:46,47, CH4:byte 64,65) Status of the response Value...
  • Page 22 9-6 Operating example(When connected to the AD-4212C/AD-4212D) This is the procedure for performing basic operations on the weighing device via EtherNet/IP communication. (Describes the case where a weighing device is connected to CH1. When using CH2, 3, 4, make the data layout correspond to the relevant CH (channel).) ■How to read the weighing value (Weighing device CH1)) Input data layout Output data layout...
  • Page 23 ■Example of calibration (sensitivity adjustment) with external weight(Possible only with AD-4212C/AD-4212D) Input data layout Output data layout Steps Items Contents (Instance150 ,Attribute3) Status confirmation contents (Instance100 ,Attribute3) AD-4212C AD-4212D Instructs to start the sensitivity Byte 0,1 [CH1 Command] Sets "1" to the corresponding data layout adjustment mode bit 1‟CAL”...
  • Page 24 5.Normally, changes immediately after setting “1” to bit in the previous step. ※ 6 . If the weighing value is unstable, Sensitivity adjustment completed (0x0005) is not entered, and it switches automatically to weighing mode. Also, if the weighing ※ value is not appropriate, Sensitivity adjustment error (0x0006) will occur.
  • Page 25: Web Interface

    10-1 Preparing for communication Prepare in the same way as "9-1. Preparation for communication" (9. EtherNet/IP). Enter the IP address of the AD-8552EIP in the address bar of your browser. Press "Connect". Enter "and" in the "Password" field and press "send Password".
  • Page 26 10-3 Weighing Device Operation Screen ・The weighing device operation screen has a mode (CH1 to 4) that displays one channel on one screen and a mode (ALL) that displays four channels. ■1 channel display (CH1 to 4) ① Weighing display ③...
  • Page 27: Network Setting Screen

    10-4 Network Setting Screen ・On the network setting screen, you can set the IP address, subnet mask, and default gateway. Set SW-1: 0 and SW-2: 0, and then turn the power off and then on again to reflect the changes in the settings. SW2 ×1 SW1 ×16 Note...
  • Page 28: Troubleshooting

    ・Is the EtherNet/IP communication cable broken? ・Is the scanner turned on? Turn the power of the AD-8552EIP off and then on again. When the power is turned IP address cannot be changed on, the changes made to the switch and WEB interface are read and reflected in the operation.
  • Page 29 A&D Company, Limited 3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013, JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-1566 A&D ENGINEERING, INC. 47747 Warm Springs Blvd, Fremont, California 94539, U.S.A. Tel: [1] (800) 726-3364 Weighing Support:[1] (888) 726-5931 Inspection Support:[1] (855) 332-8815 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420...
