Extron electronics PS 150 Specifications

Specifications — PS 150 Power Supply
Specifications
Power input 100VAC to 240VAC, 50/60 Hz, internal, 100 watts
Power output (6) 15VDC outputs (maximum current of all outputs 5 0 A)
Temperature/humidity Storage -40° to +158°F (-40° to +70°C) /10% to 90%, non-condensing
Cooling Convection, vents on left and right sides
Mounting
Rack mount Yes, with optional 1U, 9 5" deep rack shelf, part #60-190-01 (RSU 129) or
Furniture mount Yes, with optional under-desk mounting kit, part #70-222-01 (MBU 149)
Enclosure type Metal
Enclosure dimensions 1 75" H x 4 4" W x 8 5" D (1U high, quarter rack width)
Product weight 1 2 lbs (0 5 kg)
Shipping weight 3 lbs (2 kg)
Vibration ISTA/NSTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety CE, CUL, UL
EMI/EMC CE, C-tick, FCC Class A, ICES, VCCI
MTBF 30,000 hours
Warranty 3 years parts and labor
N Specifications are subject to change without notice.
Operating +32° to +113°F (0° to +45°C) /10% to 90%, non-condensing
60-604-01 (RSB 129)
(4 4 cm H x 11 2 cm W x 21 6 cm D)
Extron PS 150 Power Supply • Specifications
7.6-102708-D3
1
