Volvo A35e Fs Articulated Dump Truck
Workshop Service Repair Manual
Volvo A35E FS A35EFS Articulated Dump Truck Service Repair Manual INSTANT
DOWNLOAD
Volvo A35E FS A35EFS Articulated Dump Truck Service Repair Manual is an electronic
version of the best original maintenance manual. Compared to the electronic version
and paper version, there is a great advantage. It can zoom in anywhere on your
computer, so you can see it clearly. Your Volvo A35E FS A35EFS Articulated Dump
Truck parts correspond with the number of pages printed on it in this manual, very easy
to use.
Advertisement
Related Manuals for Volvo A35e Fs
Summary of Contents for Volvo A35e Fs
- Page 1 It can zoom in anywhere on your computer, so you can see it clearly. Your Volvo A35E FS A35EFS Articulated Dump Truck parts correspond with the number of pages printed on it in this manual, very easy...
-
Page 2: Service Information
Description Articulated haulers A35E/A40E and A35E FS/A40E FS consist of two main sections, the tractor unit and the load unit. The two units are joined by means of the articulation joint, which allows movement about a vertical bearing for steering. The articulation joint also allows the units to rotate in relation to each other around the longitudinal axis. - Page 3 Coolant with anti-freeze and corrosion protection, recommendation Coolant The cooling system is filled with Volvo Coolant VCS. Always use the same coolant that the system was previously filled with. NOTE! To avoid damage to the engine, different coolants must NOT be mixed. Nor may pure water be used alone.
- Page 4 Service Information 2014/8/27 Profile: ART, A25E, A40E FS, A40E, A35E FS, A35E, A25E 4x4, A30E [GB] Recovering and towing WARNING Before starting any recovery or towing work, make sure that the parking brake is applied and the wheels are blocked to prevent the machine from rolling.
-
Page 5: Lifting Machine
Information Type: Date: Lifting machine Service Information 2014/8/27 Profile: ART, A35E, A35E FS, A40E, A40E FS [GB] Lifting machine Op nbr 09001-1 WARNING Never stand under the machine when it is suspended in the air. WARNING The lifting tool may only be installed with the special nuts supplied with the tool. - Page 6 Steering joint lock 4. Fit the lifting tool onto the front axle and the front bogie axle and tighten the nuts crosswise 200 Nm (148 lbf ft). Figure 2 WARNING Do not lift the machine by the load body eyes. The four lifting slings must have the same length and be at least 8.5 m (335 in) 5.
- Page 7 Service Information Document Title: Function Group: Information Type: Date: Drawings of E-tools Service Information 2014/8/27 Profile: ART, A35E FS [GB] Drawings of E-tools E-2503 Measuring nipple Figure 1 E-2503 Measuring nipple...
- Page 8 Volvo CE's machines. The lifting tool is intended to be used globally in Volvo workshops. Intended users of the lifting tool are persons appointed by each Volvo workshop. The lifting tool may not be used by unauthorized persons or minors.
- Page 9 Figure 3 Lifting tool 88830051 connected to engine D12D Figure 4 Lifting tool 88830051 connected to engine D16E Safety General Read the user instruction before use or in connection with initial use, pay special attention to the publication's warning texts. Use restrictions Application Do not use and overload the lifting tool and its connected lifting...
- Page 10 Personnel requirements Personnel shall be aware of the risks associated with being in or near the risk area where loads are lifted. Personnel shall also have sufficient instructions to be able to use the lifting tool in a safe way. Authorization It is the employer's and the management's responsibility to make sure that persons only are authorized to handle the tools for which they...
- Page 11 Lifting eye with pins that are to be adapted to each engine's rear hole pattern. Lifting eye for connecting lift hook with chain that is to be installed depending on the engine to be lifted. Outer square pipe with pins. Inner square pipe with telescopic function that is length-adapted/rotated 180°...
- Page 12 Figure 12 Ratchet block 1.5 ton Connecting lifting tool to engine D9B Figure 13 Engine D9B Figure 14 Inner pipe with telescopic function is adapted to the short position and turned down according to the figure (4, 7.) Install the pins and secure them with the lock pins.
- Page 13 Connect the lifting hook to the inner hole. Permanent connection with shackle. Connect the lift ring with chain from the ratchet block. Install the pin and secure it with the lock pin. 5, 6, 7 - Connect the lifting tool to the engine's attaching points. Install the pins and secure them with the lock pins. Lift carefully and adjust the lift angle with the ratchet block, depending on the engine and machine being handled.
- Page 14 Volvo A35E FS A35EFS Articulated Dump Truck Service Repair Manual is a perfect manual, which contains a lot of information. I believe that would be what you need. Covers the following serials: Serial numbers: ALL Service Repair Manual Covers: Safety...
