  • Page 1 E80 GbW F80 GbW OPERATING MANUAL E80 GbW F80 GbW www.mahlkoenig.de...

  • Page 2: Overview

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Overview F80 GbW E80 GbW...
  • Page 3 E80 GbW | F80 GbW | EN Not relevant for F80 GbW.
  • Page 4 ESPRESSO GRINDER | FILTER COFFEE GRINDER...
  • Page 5 E80 GbW | F80 GbW | EN...
  • Page 6 ESPRESSO GRINDER | FILTER COFFEE GRINDER...
  • Page 7 E80 GbW | F80 GbW | EN...
  • Page 8 ESPRESSO GRINDER | FILTER COFFEE GRINDER Material Weight Description...
  • Page 9 E80 GbW | F80 GbW | EN...

  • Page 10: Scope Of Delivery

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Scope of delivery No. Designation No. Designation Locking screws for grinder lid Bean hopper (with lid) Lock/Unlock grinder lid Bean hopper intake Grinder lid Controller Screws for fixed grinding discs Grinding degree lock Screws for rotating grinding On/Off switch discs Release button (Thermal...

  • Page 11: Table Of Contents

    E80 GbW | F80 GbW | EN Contents Overview ......2 Interrupting grinding ....27 Rescue button grinding ....27 Scope of delivery ....10 Changing the coffee bean type ... 28 General Information ..12 Using the main menu ..29 Reading and retaining Display/navigation symbols ..

  • Page 12: General Information

    European Union. Please also note the guidelines and laws of your specific country if abroad. For better clarity, the E80 GbW/F80 GbW grinder will be referred to hereinaf- ter only as “grinder". Keep this operating manual for future reference.
  • Page 13 E80 GbW | F80 GbW | EN This symbol indicates important information concerning opera- tion or handling. Declaration of Conformity: Products marked with this symbol fulfil all applicable community provisions of the European Economic Area. ETL Listed seal of approval: Products marked with this symbol meet the requirements of electrical product safety in the United States of America.

  • Page 14: Safety

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Safety Intended use The grinder is only suitable for grinding whole roast coffee beans. Do not use the grinder for grinding other products or objects. The grinder is intended for commercial use but not for continuous mass pro- duction.
  • Page 15 E80 GbW | F80 GbW | EN – Only install the grinder at places where the handling of the grinder can be supervised by trained personnel. – Do not operate the grinders above 2,000 metres. – Do not immerse the grinder or the power cable or power plug in water or any other liquids.
  • Page 16 ESPRESSO GRINDER | FILTER COFFEE GRINDER WARNING! Danger for children and persons with reduced physical, sensory or mental capabilities (e.g. partially disabled persons, older persons with limited physical and mental capabilities) or a lack of experience and knowledge (e.g. older children). –...

  • Page 17: Before Commissioning

    E80 GbW | F80 GbW | EN Before commissioning Functioning and basic settings The grinder is equipped with the grind-by-weight technology (GbW) for dosing via weight control in real time. It also has a Disc Distance Detection (DDD) function which enables the grinding degree to be set on the basis of the distance between the grinding discs.

  • Page 18: Check The Grinder And Scope Of Delivery

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Check the grinder and scope of delivery NOTE! Risk of damage! Take care when opening the packaging with a sharp knife or other pointed objects, otherwise the grinder may be damaged. – Be very careful when opening the packaging. 1.

  • Page 19: Setting Up The Portafilter Support And Spout

    E80 GbW | F80 GbW | EN If the bean hopper cannot be fixed in place by turning it, it may not be positioned correctly. In this case, align the bean hopper correctly (see step 5) and then try again by pressing it down and turning it (see also the chapter on “Troubleshooting”).

  • Page 20: Activating Portafilter Detection

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Activating Portafilter Detection Portafilter Detection (PFD) must be activated before it can be used for grinding. 1. Switch on the grinder by setting the On/Off switch (5) to the I position. The grinder is ready for operation as soon as the last selected recipe or the start screen appears on the display (14).

  • Page 21: Detecting The Portafilters / Filter Baskets

    E80 GbW | F80 GbW | EN Detecting the portafilters / filter baskets • Each portafilter/filter basket must be registered by means of Portafilter Detection (PFD) in a so-called "learning process", so that the grinder automatically detects different portafil- ters/filter baskets.

  • Page 22: Operation

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Operation NOTE! Danger of overheating! Exceeding the maximum permissible operating cycle can cause the grinder to overheat. – Do not exceed the maximum operating cycle (see chapter on “Technical data”). – Observe the recommended pause when the maximum permis- sible operating cycle is reached (see chapter Technical data “...

  • Page 23: Filling With Coffee Beans

    E80 GbW | F80 GbW | EN Filling with coffee beans 1. Remove the lid from the bean hopper (1). 2. Fill the bean hopper with whole roasted coffee beans from above. • The maximum filling quantity should be approx. 1 cm below the edge of the bean hopper.

  • Page 24: Selecting A Recipe On A Weight/Time Basis

    ESPRESSO GRINDER | FILTER COFFEE GRINDER • Decrease the grinding degree only when the grinder is in operation. • To avoid/eliminate imbalances when adjusting the grinding degree, we recommend that you first set a coarser grind- ing degree (about one step/unit above the desired grinding degree) and only then adjust the grinding degree slider down from there to the desired finer grinding degree.

  • Page 25: Setting Or Changing The Grinding Weight/Grinding Time

    E80 GbW | F80 GbW | EN Setting or changing the grinding weight/grinding time Proceed as follows if you wish to set the grinding weight/grinding time of a new recipe or wish to change that of an existing recipe: 1. Select the desired recipe by turning the controller (3) (see chapter on “Selecting a recipe on a weight/time basis“).

  • Page 26: Starting Grinding

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Starting grinding • When grinding in the Portafilter mode, the grinder automati- cally calls up the appropriate recipe for the detected portafil- ter/filter basket. • If Portafilter Detection (PFD) is deactivated for weight-based grinding, the weight of the portafilter/filter basket is detected and automatically zeroed as soon as you push the portafilter/ filter basket between the portafilter intake and the portafilter support/basket holder and release it (the LED light changes...

  • Page 27: Interrupting Grinding

    E80 GbW | F80 GbW | EN Interrupting grinding Weight-based recipes cannot be interrupted, because the porta- filter/filter basket is zeroed each time it is inserted in the porta- filter intake and the grinding process starts again. Grinding is automatically interrupted when you remove the portafilter/filter basket from the portafilter intake(12).

  • Page 28: Changing The Coffee Bean Type

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Changing the coffee bean type 1. Close the bean hopper (1) by sliding in the funnel slide (18). 2. Grind any coffee beans left in the grinding mechanism until the grinder runs empty. 3. Use a slot screwdriver to undo the securing screw (19) for the bean hopper.

  • Page 29: Using The Main Menu

    E80 GbW | F80 GbW | EN Using the main menu You can use the main menu to retrieve appliance data and change certain settings. Display/navigation symbols Symbol Meaning “Warning & messages” menu item “Statistics” menu item “Edit recipes” menu item “Service”...

  • Page 30: Accessing And Operating The Main Menu

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Accessing and operating the main menu 1. Press the controller (3) twice to call up the main menu in the display (14). 2. Turn the controller to select the desired recipe (see chapter on “Display/navigation symbols”).

  • Page 31: Cleaning

    E80 GbW | F80 GbW | EN Cleaning CAUTION! Risk of injury! When moved, the grinder may fall down and injure you. – Always place the grinder on a stable surface that is safe from tipping over. – If necessary, ask another person to help if the grinder is too heavy.

  • Page 32: Cleaning The Grinder Installation Surface

    • the portafilter intake/basket holder /(12), (11), • the portafilter support ONLY RELEVANT FOR E80 GBW • the screws (8) for adjusting the portafilter support (left and right). 3. Pull the drip tray (10) forward and out of the grinder.

  • Page 33: Cleaning The Spout System

    E80 GbW | F80 GbW | EN Cleaning the spout system The manufacturer recommends using a brush with nylon bristles to clean the spout system. 1. Pull the spout (13) downwards out of the lock (see Fig. H). 2. Use a brush to clean the spout on the casing (spout locking mechanism).

  • Page 34: Cleaning The Grinding Mechanism With Grindz Tm

    ESPRESSO GRINDER | FILTER COFFEE GRINDER 10. Use a slot screwdriver to tighten the securing screw (19) for the bean hopper clockwise. 11. Pour the coffee beans back into the bean hopper. 12. Open the bean hopper by pulling out the hopper slide. Cleaning the grinding mechanism with GRINDZ •...

  • Page 35: Cleaning The Grinding Mechanism Manually

    E80 GbW | F80 GbW | EN 13. Press the upper button (23) to start the grinding process and keep it pressed down until the grinder cleaner has been completely ground. 14. Grind approximately the same amount of coffee beans as you did grinder cleaner, in order to remove leftover cleaning particles.

  • Page 36: Cleaning The Flapper

    ESPRESSO GRINDER | FILTER COFFEE GRINDER 9. Place the fixed disc flange on the grinding chamber. We recommend cleaning the flapper (34) during this step (see “Cleaning the flapper”, steps 2–4). 10. Turn the fixed disc flange anticlockwise and tighten the three securing screws with a slot screwdriver.

  • Page 37: Maintenance

    E80 GbW | F80 GbW | EN Maintenance Changing the grinding discs • The grinding discs should be changed after grinding around 1500 kg of coffee beans. The weight in kg depends on the grinding degree, coffee bean type, degree of roasting and condition of the grinding discs.

  • Page 38: Adjusting The Grinding Discs

    ESPRESSO GRINDER | FILTER COFFEE GRINDER 8. Use a wire brush to clean the fixed disc flange and the screw holes. Make sure that the fixed disc flange is completely clean. 9. Place the new fixed grinding disc on the fixed disc flange and use a slot screwdriver to tighten the two screws.

  • Page 39: Changing The Flapper

    E80 GbW | F80 GbW | EN Changing the flapper Change the flapper if it is porous, deformed or very dirty. 1. Remove the grinder lid (26); proceed as described in the chapter on “Cleaning the grinding mechanism manually”, steps 1–5.

  • Page 40: Troubleshooting

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Troubleshooting Fault Cause Remedy • The power t Insert the power plug into a properly The grinder is plug is not installed socket. not grinding, plugged into a the display is socket. not lit up. •...
  • Page 41 E80 GbW | F80 GbW | EN Fault Cause Remedy The grinder • The grinding t Release the grinding degree adjustment is making mechanism is lock and set the grinding degree to "8". noise but not clogged. Start the grinding process.
  • Page 42 ESPRESSO GRINDER | FILTER COFFEE GRINDER Fault Cause Remedy • The grinder is t The load cell must be calibrated The grinder is not measuring. (see chapter on “Calibrating the not grinding, load cell“). the display is permanently red. • The grinding t Clean/change the grinding discs or The grinder is discs are worn...
  • Page 43 E80 GbW | F80 GbW | EN Fault Cause Remedy The grinder’s • The ambient t The scales must be calibrated dispensing conditions (see chapter on “Calibrating the accuracy is have changed, load cell“). decreasing. e.g. the instal- lation location.
  • Page 44 ESPRESSO GRINDER | FILTER COFFEE GRINDER Fault Cause Remedy The grinder • The fixed t Align the fixed disc flange correctly lid cannot be disc flange is (see chapter on “Cleaning the grinding attached. not mounted discs“). correctly. • The adjust- t Align the adjustment ring correctly ment ring is (see chapter on “Zeroing the grinding...

  • Page 45: Technical Data

    E80 GbW | F80 GbW | EN Technical data Model: E80 GbW / F80 GbW Voltage / frequency: 100 V; 50/60 Hz 110–127 V; 60 Hz 220–240 V; 50/60 Hz Protection type: IPX1 Protection class: Fuse: 16 A, slow-blowing/15 A...

  • Page 46: Disposal

    ESPRESSO GRINDER | FILTER COFFEE GRINDER Disposal Disposing of the packaging Dispose of the packaging by correctly sorting the recyclable ma- terials. Dispose of card and cardboard as waste paper and film as recyclable material. Disposing of the grinder Old appliances may not be thrown into commercial/domestic waste! As a consumer, you are required by law to dispose of old equip- ment separately from commercial/household waste, e.g.
