ITEM NO.98295 BAR CART
1
SIDE PANEL
2PCS
4
GLASS TOP
1PC
A
BOLT 1/4"x 7/8"
8PCs
D
CASTER WITH BRAKE
2PCS
G
ALLEN WRENCH
1PC
ASSEMBLY
METAL FRAME
MIRROR SHELF
BOLT 1/4" x 1-1/2"
BOLT COVER CAP
PEN WRENCH
INSTRUCTIONS
2
2PCS
5
1PC
B
4PCS
E
4PCS
H
1PC
3
STRETCHER
2PCS
C
CASTER
2PCS
F
GLASS PAD
12PCS
Advertisement
Table of Contents
Related Manuals for Acme Furniture Traverse 98295
Summary of Contents for Acme Furniture Traverse 98295
- Page 1 ITEM NO.98295 BAR CART ASSEMBLY INSTRUCTIONS SIDE PANEL METAL FRAME STRETCHER 2PCS 2PCS 2PCS GLASS TOP MIRROR SHELF BOLT 1/4” x 1-1/2" BOLT 1/4”x 7/8" CASTER 8PCs 4PCS 2PCS CASTER WITH BRAKE BOLT COVER CAP GLASS PAD 2PCS 4PCS 12PCS ALLEN WRENCH PEN WRENCH...
- Page 2 *** Do not tighten screws & bolts until the entire unit is completely assembled. *** STEP 1 Attach metal frame (2) to side panel (1) using bolts (A), and attach stretcher (3) to side panel using blot (B) as shown. STEP 2 Attach the other side panel (1) to metal frame (2) using...
- Page 3 STEP 3 Attach caster (C) and caster with brake (D) to side panels by open wrench (H) as shown. Tighten all bolts and carefully turn the assembled unit upright. STEP 4 Use bolt covers cap (E) to caver the exposed bolts on side panels and attach glass pad (F) to metal frames.
