John Lewis JLBIHD906 Instruction Manual

John Lewis JLBIHD906 Instruction Manual

Built-in cooker hood
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
JLBIHD906
built-in cooker hood
Instruction manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JLBIHD906 and is the answer not in the manual?

Questions and answers

Related Manuals for John Lewis JLBIHD906

Summary of Contents for John Lewis JLBIHD906

  • Page 1 JLBIHD906 built-in cooker hood Instruction manual...

  • Page 2: Important Safety Information

    Important Safety Information It is most important that this instruction manual should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.

  • Page 3: Table Of Contents

    Contents For the User Important Safety Information Description of the Appliance Using the cooker hood Cooker Hood Controls To Operate Recirculation Extraction Maintenance and Cleaning External Cleaning Cleaning the Comfort panels Metal Grease Filters Charcoal Filters To Remove/Replace Charcoal Filter Changing the Halogen Spot Lamp Something Not Working Repairs and After Sales Service...

  • Page 4: Description Of The Appliance

    Description of the Appliance...

  • Page 5: Installing The Cooker Hood

    Installation Please ensure that when the appliance is installed it is easily accessible to an engineer in the event of a breakdown. All installations must comply with the local authorities requirements for the discharge of exhaust air. Incorrect installation may affect the safety of this cooker hood. Installation Requirements Before installation check the wall to which the cooker hood is to be fitted for electric cables, water pipes or gas.

  • Page 6: Drilling The Ceiling/Support Shelf

    Installing the Cooker Hood In all cases where the ceiling is not strong enough at the suspension point, the installer must provide strengthening using suitable plates and backing pieces anchored to the structurally sound parts. Drilling the Ceiling/Support Shelf • Use a plumb line to mark the centre of the hob on the ceiling/support shelf.

  • Page 7: Extraction

    • Lift up the frame, fit the frame slots onto the screws up to the slot end positions. • Tighten the two screws and fasten the other two screws provided with the hood. Before tightening the screws completely it is possible to adjust the frame by turning it.

  • Page 8: Recirculation

    Recirculation Mode The cooker hood is supplied specified for use in the recircula- tion mode, with the charcoal filter fitted. In the recirculation mode contaminated air is passed through the charcoal filter to be purified and recirculated into the kitch- en through the grille outlets on either side of the chimney.

  • Page 9: Electrical Connections

    Electrical Connections THIS APPLIANCE MUST BE EARTHED Electrical Requirements Any permanent electrical installation must comply with the latest I.E.E. Regulations and local Electricity Board regulations. For your own safety this should be undertaken by a qualified electrician e.g. your local Electricity Board, or a contractor who is on the roll of the National Inspection Council for Electrical Installation Contracting (NICEIC).

  • Page 10: Using The Cooker Hood

    Using the cooker hood The cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. The appliance can be installed to recirculate or extract contaminated air. To Operate Select the required fan speed and light if required. Recirculation In the recirculation mode the contaminated air enters the cooker hood through the grease filters.
  • Page 11 Touch Basic functions control Dual Function When briefly pressed it switches the light- ing system on and off. When pressed for 2 seconds it switches the electroluminescent lighting on and off. This function is independent from the basic functions of the control unit.

  • Page 12: Maintenance And Cleaning

    Maintenance and Cleaning Before carrying out any maintenance or lean- ing isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent.

  • Page 13: Charcoal Filters

    Cleaning the filters • Pull the Comfort Panel to open it. • Remove the filters one by one pushing them towards the back side of the unit and simultaneously pulling downwards. • The metal grease filters can be washed, by hand, in mild soapy water or in a dishwasher.

  • Page 14: To Remove/Replace Charcoal Filter

    To Remove/Replace the Char- coal Filters • First remove the metal grease filters. • Remove the saturated activated charcoal filter by releasing the fixing hooks as illustrated. • Position the new charcoal filter in the position marked and while holding the filter replace the fixing hooks as illustrated Reset the alarm signal •...

  • Page 15: Something Not Working

    Something not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force agent. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or instal- lation, a charge will be made even if the appliance is under guarantee.
  • Page 16 John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.com 436003471_03 - 070625 0607...
