- Page 1 Instructions–Parts ® RAZOR Gravity Feed Gun 311684P A premier gun for the automotive refinish market Includes LVLP, HVLP, Compliant, and Conventional Series. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. ti8206 II 2 G...
- Page 2 Models Models / Modèles / Modelos Air Cap with Max HVLP/ Part Nozzle Needle Needle Retaining Comp Pressure Number Series Spray Type (mm) Application Nozzle Assy Ring psi (MPa, bar) LVLP 16 (0.1, 1.1) Clear, Base 253823 253802 253771 288752 289500 253427 LVLP...
- Page 3 Models Air Cap with Max HVLP/ Part Nozzle Needle Needle Retaining Comp Pressure Number Series Spray Type (mm) Application Nozzle Assy Ring psi (MPa, bar) 289214 HVLP 29 (0.2, 2.0) Metallic 289212 253794 253771 288752 289514 289215 HVLP 29 (0.2, 2.0) Metallic 289212 253795 253772 253917 289514...
- Page 4 Check equipment daily. Repair or replace worn or damaged parts immediately. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your Graco distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
-
Page 5: Operation
Setup WARNING PERSONAL PROTECTIVE EQUIPMENT You must wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic fumes, burns, and hearing loss. This equipment includes but is not limited to: •... -
Page 6: Volatile Organic Compounds (Voc) Regulation
Maintenance Volatile Organic Compounds Cleaning Gun and Cup (VOC) Regulation CAUTION • Do not submerge gun in solvent. Solvent In certain states, spraying solvents that release dissolves lubricant, dries out packings, VOCs into the atmosphere when cleaning a and clogs air passages. spray gun is prohibited. - Page 7 Repair Compliant Cleaning Methods Air Valve Replacement 1. Place spray gun in a gun washer that com- 1. Remove trigger nut (24), trigger pin (23), pletely encloses the gun and components wave washer (18), and trigger (10). during cleaning, rinsing, and draining. 2.
-
Page 8: Fluid Inlet Fitting Replacement
Repair Fluid Inlet Fitting Replacement PRESSURIZED EQUIPMENT HAZARD • Fluid inlet gasket (3) must be replaced if fluid inlet fitting (4) is removed from spray gun. • Failure to replace gasket (3) may result in air leakage into the fluid section causing a non-vented gravity cup to become pressurized. -
Page 9: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Normal pattern. No action necessary. Right Dirty or damaged air cap or fluid Rotate air cap 180°. nozzle. If pattern follows air cap, problem is in air cap (13). Clean and inspect. If pattern is not corrected, replace air cap. -
Page 10: Technical Data
Troubleshooting Technical Data Maximum Air Inlet Pressure ..... . 100 psi (0.7 MPa, 7 bar) Maximum HVLP/Compliant Inbound Air Pressure: LVLP gravity feed . - Page 11 Accessories Accessories Repair Kits Cups Part No. Description Part No. Description 253748 Needle Packing Repair Kit 253977 Aluminum Gravity Feed Cup 23 oz 253783 Gun Repair Kit (650 cc) 253784 Air Cap Seal Kit 253978 Aluminum Gravity Feed Cup 34 oz 253785 Trigger Repair Kit (1 liter) 253933 Air Inlet Fitting Repair Kit...
- Page 12 Parts Parts 7‡ 28*✿ ✠ 8‡ 23** ‡29 18** *‡22 ‡31 *‡22 19*◆✓ *‡6 13✓ 20*◆✓ *†16 *†15 **24 10** 14✓ TI8205 Pull trigger before installing nozzle (11). Insert spreader (15) with tapered end facing rear of gun. Insert u-cup (16) with open end facing front of gun.
- Page 13 Parts * Included in Gun Repair Kit 253783 (purchase Ref. separately). Part No. Description Qty. ** Included in Trigger Repair Kit 253785 (purchase separately). BODY, gun † Included in Needle Packing Repair Kit 253748 3*✠ GASKET, fluid inlet (purchase separately). 253971 FITTING, fluid inlet, ‡...
