- Page 1 Installation LineLazer lV Second Gun Kit 287553 311066C 3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure ti6545a Important Safety Instructions Read all instructions and warnings in manuals 311020, 311021, or 313775. Save these instructions.
- Page 2 ti6655a ti6654a ti6656a Relieve pressure. Refer to Install extension clamp (10) Pull out existing gun arm Slide extension clamp onto and extension support support bracket existing gun arm support your sprayer manual. bracket (12)) bracket ti6658a ti6657a ti6659a ti6660a Install existing gun support Install extension support Route gun cable (1) up to Insert gun cable through...
- Page 3 ti3331a ti6664a ti3332a ti3342a ti3330a ti6549a Align guns Position guns: up/down, Connect gun cables to left One gun: Disconnect one forward/reverse, left right or right, or both, selector gun selector plate from trig- plates ger. Both guns simultaneously: Adjust both gun selector plates to the same position.
- Page 4 ti6546b Part Description Part Description 111145 KNOB, pronged 287696 CABLE, gun 188135 GUIDE, cable 15F212 ARM, holder, gun 224136 CLAMP, extension 119648 SCREW, mch, trsshd, cross recess 248157 GUN, flex, basic 287566 KIT, clamp 224096 BRACKET, support, extension 287570 HOLDER, gun; includes 5a - 5f 245798 HOSE, 1/4 in.
- Page 5 311066C...
- Page 6 For the latest information about Graco products, visit www.graco.com. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
