59503
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instruction in the same sepuence as numbered to assure fast & easy assernbly.
Warning!
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intendedfor commercial establishment.
CHAIR
A
B
FRONT LEGS
ACME
ASSEMBLY INSTRUCTION
ASSEMBLY TIME PER UNIT:
PARTS IDENTIFICATION
1 PC
4 PCS
HARDWARE PACKAGE
NO
DESCRIPTION
BOLTS 5/16 "
1
WRENCH
2
SPRING
3
GASKETS
4
WASHERS 5/16"
1 Of 2
FIGURE
QTY
8 PCS
1 PC
8 PCS
8 PCS
