Fronius DRM Interface - Installation
Incorrect operation and work performed incorrectly can cause serious injury and damage
to property.
Only qualified staff are authorized to do installation work in the inverter and only within the
scope of the respective technical regulations.
Do not carry out any installation or maintenance work until you have read the "Safety"
chapter in the installation manual of your inverter.
For further details see the installation manual of your inverter.
In order to control an inverter via Demand Response Modes (DRM) according to AS4777.2:2020, the
Fronius DRM Interface must be installed in the inverter.
1
1
2x TX25
1
3
+
4
*
TX20
9 mm
42,0410,2292 002 - 30112021
*
2
TX20
1
2
1
1
4
Fronius International GmbH, http://www.fronius.com
2
Advertisement
Table of Contents
Related Manuals for Fronius DRM
Summary of Contents for Fronius DRM
- Page 1 For further details see the installation manual of your inverter. In order to control an inverter via Demand Response Modes (DRM) according to AS4777.2:2020, the Fronius DRM Interface must be installed in the inverter.
- Page 2 1/5 = DRM1/5 | 2/6 = DRM2/6 | 3/7 = DRM3/7 | 4/8 = DRM4/8 | RG/0 = REF GEN/0 | CL/0 = COM LOAD/0 I5 IO3 IO1 GND GND D- I4 IO2 IMPORTANT! When a Fronius DRM Interface is installed in the inverter, do not connect any external voltage to the 12V+ and GND pins of the Datamanager! ... NO EXTERNAL VOLTAGE For more details regarding connection and adjustment see the Datamanager manual.
