SV8D Quick Start Guide
[iv]
[iii]
[ii]
SV8D
_______________________________________________________________________________________________
Preparing the SV8D
Steam Operation:
1. Plug cable into a wall outlet. NOTE: Do NOT use
multi-outlet power-boards and avoid using low-quality
extension cables.
2. Open water tank filler cap (iii), fill tank with clean tap
water up to the top then close filler cap. NOTE: Do NOT
use de-mineralised water and do NOT fill with any
chemicals.
3. Turn SV8D on using the ON/OFF switch (i), making
sure the steam level lights on the display (g) lights up
after a few seconds.
4. Connect hose into the SV8D by opening the
protective plastic flap located on the front of the
machine (ii) and pushing the plug end of the hose in
with the round red button on the top side of the hose
until it clicks.
Proceed to "Vacuum Operation" and/or "Detergent
Operation" section if you are planning on using the vacuum
and/or detergent functions together with the steam
functions.
Vacuum Operation:
1. Turn the vacuum on from the hose controls by quick-
pressing (V).
The SV8D will make a beeping noise and the vacuum
waste tank lights (b) will flash
on the display.
2. Open the transparent
vacuum cover (iv), remove
blue foam filter and slowly fill
clean tap water into the
rectangular hole on top of the
vacuum waste tank until the
vacuum waste tank lights (b)
stops flashing.
3. Replace the blue foam filter
and the transparent vacuum cover (iv).
Tel: 1300 79 50 50 E-mail:
[a][b][c][d]
[e]
[f]
[i]
SV8D Display
info@steamaustralia.com.au
[V]
[L]
[g]
[S]
SV8D Hose Controls
NOTE: If the vacuum waste
tank lights (b) still flashes after
filling the tank up, remove the
plastic part with
rectangular hole, then remove
the plastic divider underneath.
You will see a white float,
make sure the white float's
surrounding areas and the
float itself is clean and can
move freely. Re-assemble the waste tank, fill the tank
with clean tap water until the vacuum waste tank lights
(b) stops flashing then put the blue foam filter and
transparent vacuum cover (iv) back on.
Detergent Operation:
1. Open transparent vacuum
cover (iv) and locate the
detergent tank filler cap.
2. Remove the detergent tank
filler cap and fill with the
diluted 101 degreaser solution. NOTE: We recommend
using Steam Australia's 101 degreaser or similar to
ensure it does not impact machine operation and/or
cause adverse health issues.
3. Replace the detergent filler cap and the transparent
vacuum cover (iv) before operating.
Hose Handle Operations
Steam Functions:
1. After 5-6 minutes the 'Steam Ready' lights (d) will
light up on the display and the steam function is ready
for use. Make sure the steam level lights (g) is on,
otherwise quick-press the
the steam level lights turn on to prepare the steam
function for use.
2. If the SV8D makes a beeping noise and the 'Low
Water' lights (c) flashes, proceed to Step 2 of
"Preparing the SV8D | Steam Operations".
Web: www.steamaustralia.com.au
[T]
the
RED steam button (S) until
