JUPITER SD Quick Start Guide
i
ii
iii
iv
JUPITER SD
_______________________________________________________________________________________________

Preparing the JUPITER SD

Steam Operation:

1. Plug cable into a wall outlet. NOTE: Do NOT use
multi-outlet power-boards and avoid using low-
quality extension cables.
2. Open water
tank filler cap (i),
fill tank with clean
tap water up to
the top then close
filler cap. NOTE:
Do NOT use de-
mineralised water
and do NOT fill with any chemicals.
3. Turn JUPITER on using the ON/OFF switch (a). The
switch should light up to indicate that it is functional.
4. Press the 'Boiler Switch' button (e) to start the
boiler. The green "Pump Ready" lights will flash,
indicating that the JUPITER is preparing the boiler.
5. Once the "Pump Ready" green
light stops flashing and becomes
fully illuminated, the machine will
be at pressure (c) and the steam
function ready for use.
6. Connect hose into the JUPITER by
opening the protective plastic flap
located on the front of the machine (iv) and pushing
the plug end of the hose in
with the "doman" imprint on the top side of the
hose until it clicks.
Proceed to "Vacuum Operation" and/or "Detergent
Operation" section if you are planning on using the vacuum
and/or detergent functions together with the steam
functions.
Tel: 1300 79 50 50 E-mail:
a b c
f JUPITER Display
c
info@steamaustralia.com.au
d
e
INCLUDED
S/O HOSE
g

Detergent Operation:

1. Open detergent
tank filler cap (ii),
fill tank with
detergent.
2. Remove the
detergent tank
filler cap and fill
with the diluted
101 degreaser solution up to the top. NOTE: We
recommend using Steam Australia's 101 degreaser or
similar to ensure it does not impact machine
operation and/or cause adverse health issues.
3. Replace the detergent filler cap (ii) before
operating.

Vacuum Operation: With Vac Kit

Locate the vacuum switch (S) on the vacuum head
unit (iii) and turn it on.
NOTE: The vacuum
bucket can be cleaned
by detaching the bucket
from the vacuum head
through the latch that
holds it. Always make
sure the bucket is fitted on properly to ensure that
the contents will not disperse to your surroundings.
Web: www.steamaustralia.com.au
OPTIONAL
h
k
m
T
n
S/V HOSE
JUPITER Hose Controls
ii
S
