Northern Telecom DMS-100 Series Maintenance Manual page 6

iv Contents
List of figures
Figure 1-1
Figure 1-2
Figure 1-3
Figure 1-4
Figure 1-5
Figure 1-6
Figure 1-7
List of procedures
Replacing an NT6X27CA in a PLD 4-2
Replacing an NT6X54CA in a PLD 4-4
List of tables
Table 2-1
297-2101-504 Standard 02.01 December 1991
Provision of exchange lines from a host LCM 1-3
Provision of exchange lines from a PRLCM 1-4
PLD and DMS configuration 1-5
PCM30 line drawer 1-7
LCA shelf layout 1-9
LCE frame layout 1-11
PRLCM frame layout 1-12
PLD drawer states 2-2
