Understanding the PCM30 line drawer

This chapter introduces the PCM30 line drawer (PLD). The PLD is

discussed in subsequent sections of this chapter as follows:

Application of the PCM30 line drawer on page 1-2 describes the

PLD and provides an example of its application.

System configuration on page 1-5 describes where the PLD fits into

the DMS peripheral architecture.

How the PCM30 line drawer is configured on page 1-6 describes the

physical configuration of the PLD.

How the peripheral modules are configured on page 1-8 describes

the physical configuration of the host and remote line concentrating modules

in relation to the PLD.

PCM30 Line Drawer Maintenance Guide BCS33 and up
