Anzzi FR-AZ574 Installation Manual

FR-AZ574
Installation Guide
For more information visit
www.ANZZI.com or call
1-844-44-ANZZI

DIMENSIONS

FAUCET MAINTENANCE

CARE INSTRUCTIONS

RECOMMENDED TOOLS

To keep your faucet looking its best, please follow
these simple care instructions:
DO:
1. Remove as much surface dirt and film using
clear water and a soft cotton cloth.
2. Use any of the following to remove tough
surface film and build-up:
- Mild liquid detergent
- Non-acidic, non-abrasive gentle liquid cleanser
- Non-abrasive liquid polisher.
3. Once clean, rinse faucet with clear water to
dry with soft cotton cloth.
DO NOT:
1. Use abrasive cleansers, cloths, or paper towels.
2. Use any cleaning agents containing acids, polish,
waxes, alcohol, ammonia, bleach, solvents or any
other corrosive or harsh chemical cleansers.
For Reference only (unit = mm [inch] )
thoroughly remove cleaner or polish and blot

EXPLODED DRAWING

Please read the followings before installing and usage.
Notes For reference only. We reserve the right :
to make changes without any notice.
NO. Qty
Part No Part Desc
CTHZ0301 HANDEL
01 2
02 CTWP0208 WASHER 4
CTDZ0068 ESCUTCHEON
03 2
CTST0084 SCREW
04 4
CTMB0589 ADAPTER
05 2
CTCP0384 BUSHING
06 2
CTWT0009 WASHER
07 4
08 CTST0017 SCREW 2
09 CTNZ0004 NUT 2
10 ATBA0128 CARTRIDGE(HOT) 1
CTNB0280 NUT
11 2
CTWT0066 WASHER
12 2
CTWR0207 WASHER
13 2
14 CTWR0276 WASHER 2
15 CTWT0065 WASHER 2
16 CTNT0022 NUT 2
17 CTPB0500 SHANK(HOT) 1
18 CTMZ0019 TIP 1
CTRR0164 O-RING
19 1
20 CTYB0506 SPOUT 1
2 1 CTST0137 SCREW 1
22 CTRR0055 O-RING 1
23 CTRR0138 SEAL 2
24 CTWB0089 WASHER 1
25 CTPB0405 PIPE 1
26 3
CTRR0082 O-RING
27 CTMT0032 ROD 1
28 CTBT0070 SPRING 1
29 CTRR0139 O-RING 1
30 CTDB0133 BASE 1
31 ATBP0157 HOSE 2
1
32 CTRR0137 O-RING
33 1
CTTB0035 BASE
34 1
CTCT0035 SLEEVE
35 CTWR0115 WASHER 1
36 CTWT0038 WASHER 1
37 CTNB0156 NUT 1
38 CTPB0427 CONNECTOR 1
39 1
ATBA4027 CHECK
40 1
ATBA0127 CARTRIDGE(COLD)
41 1
CTPB0501 SHANK(COLD)
42 1
ATBE0210 SHOWER
43 ATBD0080 HOLDER 1
44 ATBA0100 CHECK VALVE 1
45 1
ATBP0071 HOSE
46 1
ATBP0070 HOSE
