Anzzi L-AZ021 Installation Manual

Perfection is our Tradition
1-844-44-ANZZI or visit www.ANZZI.com
Step 3 Cleaning and care
Daily cleaning and care are required in order to keep the product shining and
properly working.
1 Clean it with water and dry it with soft cloth.
2 Clean the product with gentle liquid or glass cleaner.
Don't use acid cleaner.
3
4 Don't clean with abrasive material, abrasive paper or knife.
Step 4 Parts list
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
16
18
19
20
21
22
23
24
T M
NO. PART NAME
1 Screw
2 Screw
3 Handle
4 Cover
O-ring
5
6 Trim cap
7 Cartridge lock nut
Cartridge adapter
8
9 Cartridge
O-ring
10
25 11 Core
12 Screw
O-ring
13
14 Index
15 Screw
Body
16
Washer
17
18 Aerator core
19 Aerator collar
20 O-ring
21 Rubber washer
26
22 Clamp
23 Screw
24 Lock nut
25 Allen key
26 Flexible hose
SINGLE HANDLE LAVATORY FAUCET
ASME A112.18.1/CSA B125.1
The tools might be applied to the following places:
L-AZ021
INSTALLATION MANUAL
RECOMMENDED TOOLS
Basin wrench Channel Locks Goggles
WARNING:
Please keep the
tool for future
use!
Adjustable Wrench Teflon tape Allen key
Attention:
for easy installation, you will need:
1.To read all the installation instruction completely before
beginning.
2.To read all the warning, attention and maitenance
information.
3.To purchase the proper supply lines.
