Anzzi KF-AZ034 Installation Manual

Perfection is our Tradition
1-844-44-ANZZI or visit www.ANZZI.com
Step 4 Parts list
4
5
1
2
3
6
7
8
9
10
11
30
12
13
20
21
22
23
24
25
26
27
28
T M
NO. PART NAME
1 Aerator washer
2 Aerator core
3 Aerator collar
4 Spout
5 Screw
6 Ring
O-ring
7
8 Wearing ring
9 Connector
O-ring
10
11 Body
Cartridge
12
Cartridge adapter
13
14 Cartridge lock nut
Trim cap
15
Cover
16
17 Handle
18 Screw
19 Screw
14
15 20 Screw
16
21 Index
22 O-ring
17
Connector
23
18
24 Wearing ring
25 Rubber washer
26 Clamp
19
27 Screw
28 Lock nut
29 Plastic base
29
30 Flexible hose
SINGLE HANDLE KITCHEN FAUCET
ASME A112.18.1/CSA B125.1
The tools might be applied to the following places:
KF-AZ034
INSTALLATION MANUAL
RECOMMENDED TOOLS
Basin wrench Channel Locks Goggles
WARNING:
Please keep the
tool for future
use!
Adjustable Wrench Teflon tape Allen key
Attention:
for easy installation, you will need:
1.To read all the installation instruction completely before
beginning.
2.To read all the warning, attention and maitenance
information.
3.To purchase the proper supply lines.
