Components
Components
Main unit components
1 Main unit x 1
Interconnecting wires
4
(Video input) (6P) x 1
Splicing connector
8
x 3
GPS antenna components
GPS antenna
11
10
x 1
Wiring components
14 Wire tie
(for GPS antenna)
x 4
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor wire, radio antenna adaptor wire or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting wires
2
(Power and speaker wires,
etc) (16P) x 1
Panel
5
x 1
MAP DVD-ROM
9
x 1
Waterproof cushion Ground plate
12
x 1
- 2 -
Interconnecting wires
3
(Sub-woofer, line out, speed pulse, parking
brake, reverse, video out and steering remote
control connector)
Hex-head bolt
6 7
(Red:M5x8) x 8
Body protective sheet
13
x 1
(16P) x 1
Flat head screw
(Red:M5x8) x 8
x 1
