Trademarks

FOXWELL is the trademark of Shenzhen Foxwell Technology Co., Ltd.

All other marks are trademarks or registered trademarks of their respective holders.

Disclaimer

The information, specifications and illustrations in this manual are based on the latest information

available at the time of printing.

Foxwell reserves the right to make changes at any time without notice.

Visit our website at

www.foxwelltech.us

For Technical Assistance, send us email at

support@foxwelltech.com

T2000 TPMS Service Tool Manual_English_V1.01

Table of Contents

Need help?

Do you have a question about the T2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxwell T2000

Page 1 Disclaimer The information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Foxwell reserves the right to make changes at any time without notice. Visit our website at www.foxwelltech.us For Technical Assistance, send us email at support@foxwelltech.com...
Page 2: One-Year Limited Warranty
Foxwell. 3 The customer shall bear the cost of shipping the product to Foxwell. And Foxwell shall bear the cost of shipping the product back to the customer after the completion of service under this limited warranty.
Page 3 OF THE PRODUCT OR ARISING FROM BREACH OF THE WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY OTHER LEGAL OR EQUITABLE THEORY, EVEN IF FOXWELL KNEW OF THE LIKELIHOOD OF SUCH DAMAGES. Foxwell SHALL NOT BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE PRODUCT IS BEING REPAIRED.
Page 4: Safety Information
Do not touch engine components that get very hot when an engine is running to avoid severe ● burns. T2000 TPMS Service Tool Manual_English_V1.01...
Page 5 Block drive wheels before testing with engine running. Put the transmission in park (for ● automatic transmission) or neutral (for manual transmission). And never leave a running engine unattended. Do not wear jewelry or loose fitting clothing when working on engine. ● T2000 TPMS Service Tool Manual_English_V1.01...
Page 6: Table Of Contents
6 RKE & RF Monitor.............................. 27 7 Latest Test................................28 8 Settings................................29 8.1 Language........................................ 29 8.2 About........................................30 8.3 Keypad Test......................................31 8.4 Beeper Set......................................31 8.5 Display Test......................................32 8.6 Automatic Power-off Interval................................. 32 8.7 ID Format........................................ 33 T2000 TPMS Service Tool Manual_English_V1.01...
Page 7 8.8 Pressure Unit......................................33 8.9 Temperature Unit....................................34 8.10 Area........................................34 9 Update...................................35 9.1 Create a Foxwell ID....................................35 9.2 Register Your Scanner..................................40 9.3 Update the Scanner....................................42 T2000 TPMS Service Tool Manual_English_V1.01...
Page 8: Using This Manual
IMPORTANT indicates a situation which, if not avoided, may result in damage to the test equipment or vehicle. Example: IMPORTANT Do not soak keypad as water might find its way into the TPMS Service Tool. T2000 TPMS Service Tool Manual_English_V1.01...
Page 9: Introduction
2 Introduction 2.1 About T2000 T2000 is a professional TPMS diagnostic and maintenance tool which is capable of activating and decoding universal TPMS Sensors, programming TPMS sensors and diagnosing the original car tire pressure monitoring system. It can provide a complete solution for the TPMS service segment of the automotive aftermarket.
Page 10: Technicalspecifications
1. Press the power switch to power on the tool, and the unit will display the Main Menu. 2. Hold the power switch for one 1 seconds and the release to power down the T2000. The tool powers down automatically after a period of inactivity. Please refer to 8.6 Auto Power-off Interval for details.
Page 11: Application Overview
This section provides a brief introduction of symbols and icons of tool display. Indicator Description Indicates internal battery volume. Indicates the TPMS tool is sending signals to the tire sensor for activation and test. Indicates battery charging. T2000 TPMS Service Tool Manual_English_V1.01...
Page 12: Obd Ii
TPMS diagnosis and how to program OEM sensors etc. To test the TPMS: 1. Choose Settings--Area from the Main Menu and select the area you work. 2. Highlight TPMS from the Main Menu and press the YES key to start. T2000 TPMS Service Tool Manual_English_V1.01...
Page 13: Tpms Sensor Activate
1. In all wheel mode, the solid spot flashes at the wheel to be tested. Depending on the sensor type, place the tool to the correct position to insure sensor activation and decode. Below is a chart illustrating how to correctly place the tool. T2000 TPMS Service Tool Manual_English_V1.01...
Page 14 3. TPM data is stored and can be accessed by selecting a wheel location and press the YES key. 4. Depending on test results, one of the following possible scenarios may display. Sensor Type Illustration Description T2000 TPMS Service Tool Manual_English_V1.01...
Page 15: Tpms Diagnose
TPMS sensor was successfully activated and Successful decoded. The T2000 emits a series of tones Sensor Read and displays pressure at wheel location. The search period expires without reading a Failed Sensor TPM. The T2000 emits a single audible beep Read and displays “No sensor detected.”...
Page 16 2. Choose Read Version Information after the tool communicate with car successfully. Figure 5-8 Sample ECU Information Menu 3.The version information will be displayed. Press F2 button to save the version information or F1 or N button to exit. T2000 TPMS Service Tool Manual_English_V1.01...
Page 17 2. Choose Read Codes after the tool communicate with the car successfully. Figure 5-10 Sample Read Codes Menu 3.The fault codes will be displayed if have. Press F1 button to save the fault codes or F3 or N button to exit. T2000 TPMS Service Tool Manual_English_V1.01...
Page 18 3.There will be a notice displayed. Press F3 button to continue the operation or F1 or N button to exit. Figure 5-13 Sample Clear Codes Screen 5.2.5 Live Data To check Live Data 1. Select TPMS--Diagnose from the available menu. 2. Choose Live Data after the tool communicate with the car successfully. T2000 TPMS Service Tool Manual_English_V1.01...
Page 19 Figure 5-15 Sample Live Data Screen Figure 5-16 Sample Single Graph Screen 5.2.6 OBD Learning To enter OBD Learning 1.Select TPMS--Diagnose from the available Menu. 2.Choose OBD Learning after the tool communicate with the car successfully. T2000 TPMS Service Tool Manual_English_V1.01...
Page 20 4.If learning successfully, please re-activate the sensors and sensor pressure information will be displayed on the cluster. If failed, the cluster will not display the sensor pressure information and the TPMS MILs will turn on. Figure 5-19 Sample OBD Relearn Screen T2000 TPMS Service Tool Manual_English_V1.01...
Page 21: Tpms Sensor Programming
3.Choose the available function and follow the instructions on the tool to continue the operation. 5.3 TPMS Sensor Programming The TPMS Programming function lets users to program the sensor data to the Foxwell sensors and replace faulty sensor. There are following four options available when doing programming. Manual Create ●...
Page 22 3. Input the sensor ID in the dialog box and press Y to continue. Figure 5-23 Sample Manual Create Screen 4. Place a new Foxwell sensor near the TPMS tool (around 0-20 cm). Figure 5-24 Sample Manual Create Screen 5. Press F3 to start the programming when the tool detect the sensor.
Page 23 5.3.2 Clone By Activation The Clone By Activation function lets users automatically write in the retrieved original sensor data to the Foxwell Sensor which is used after the original sensor is triggered. To Clone by activation: 1. Highlight TPMS from the Main Menu and select the vehicle model as need.
Page 24 Figure 5-27 Sample Activation Screen 5.3.3 Automatic Create (1-16 sensors) The Automatic Create function is to program Foxwell sensors by applying random IDs created according to the test vehicle when it is unable to obtain the original sensor ID. To create sensor ID automatically: 1.
Page 25 8. Press F1 to exit after the programming successfully. Figure 5-31 Sample Programming Success Screen 5.3.4 Clone By OBD This function lets users to write in the saved sensor information to Foxwell sensors after performing Read IDs from Vehicle in Learning function. To create sensor ID manually: 1.Highlight TPMS from the Main Menu and select the vehicle model as need.
Page 26 4. Select the sensor ID to be copied after reading ID information successfully and press Y to continue. Figure 5-33 Sample ID Copy Screen 5. Place a new Foxwell sensor near the TPMS tool (around 0-20 cm). Figure 5-33 Sample Programming Screen 6. Press F3 to start the programming when the tool detect the sensor.
Page 27: Study Help
This section illustrates how to check RF Remote Keyless Entry (key FOB) with the trigger tool. The T2000 tests 315MHz and 433MHz key fobs only, and checks only for a signal present. To test the check RF Remote Keyless Entry: 1.
Page 28: Latest Test
Latest Test leads to screens for historic test records and can save 25 records at most. To test the TPM sensors: 1. Scroll with the UP/DOWN arrow keys to highlight Latest Test from the Main Menu and press the YES key to start. T2000 TPMS Service Tool Manual_English_V1.01...
Page 29: Settings
When Setup application is selected, a menu with available service options displays. Menu options typically include Language ● About ● Keypad Test ● Beep Set ● Display Test ● Automatic Power-off ● ID Format ● Pressure Unit ● Temperature Unit ● Unit ● Area ● 8.1 Language T2000 TPMS Service Tool Manual_English_V1.01...
Page 30: About
To view information of your scan tool: 1. Scroll with the arrow keys to highlight About from Settings menu and press the ENTER key. 2. A screen with detailed information of the scanner displays. T2000 TPMS Service Tool Manual_English_V1.01...
Page 31: Keypad Test
1. Scroll with the UP/DOWN arrow keys to highlight Beep Set from Settings menu and press the YES key. Press the UP/DOWN arrow key select an item and press the YES key to save and return. T2000 TPMS Service Tool Manual_English_V1.01...
Page 32: Display Test
1. Use the UP/DOWN arrow key to select Auto Power-Off from Settings screen and press the YES key to confirm. 2. Use the UP/DOWN key to increase or decrease time, and press the YES key to save and return. T2000 TPMS Service Tool Manual_English_V1.01...
Page 33: Id Format
1. Scroll with the UP/DOWN arrow keys to highlight Pressure Unit from Setup menu and press the YES key. 2. Press the UP/DOWN arrow key select an item and press the YES key to save and return. T2000 TPMS Service Tool Manual_English_V1.01...
Page 34: Temperature Unit
1. Scroll with the UP/DOWN arrow keys to highlight Area from Settings menu and press the YES key. 2. Highlight the area you work in before starting the test. And the tool will load the new database for the selected area. T2000 TPMS Service Tool Manual_English_V1.01...
Page 35: Update
9.1 Create a Foxwell ID 9.1.1 Register through Website If you are new to FOXWELL, please register on www.foxwelltech.us and create a FOXWELL ID first. If you have installed the update application FoxAssist, please refer to the registration guide on 9.1.2.
Page 36 Please always remember your FOXWELL ID and Password as it’s important for you to manager your product and updates. 4. The registration page will be bypassed, skipping to the log in page. Just input your FOXWELL ID and Password to sign in.
Page 37 Figure 9-7 Sample Password Reset Succeeded Screen 8. If you forget your email or Foxwell ID, just click Sign in at the top right of the website, then click Forgot password, and click Forget Email or Foxwell ID. You are required to input your registered serial number.
Page 38 Figure 9-9 Sample FOXWELL Search Result Screen 9.1.2 Register with FoxAssist You are also allowed to register and create a Foxwell ID with the update client FoxAssist. To register through website: 1. Visit our site www.foxwelltech.us and go the Product page. Find your product model and click it to view the product profile.
Page 39 5. A Registered account is successful message will appear if you registered successfully. Figure 9-13 Sample Registration Success Screen 6. Click OK. It skips to the login page automatically. You can input your FOXWELL ID and Password to sign in.
Page 40: Register Your Scanner
To register a scanner , you can either register on www.foxwelltech.us or by the update PC application FoxAssist. 9.2.1 Register Through Website 1. Open www.foxwelltech.us main page and click Sign in. Input your FOXWELL ID/registered email and password. Figure 9-15 Sample Sign in Screen 2.
Page 41 Warranty Card. 9.2.2 Register With FoxAssist To register with FoxAssist: 1. Launch the PC application FoxAssist. Sign in with your Foxwell ID/ registered email and password. Figure 9-18 Sample Sign in Screen 2. Select Activate and input serial number to complete product registration. If you have multiple scanners to be registered, please enter all serial numbers you wish to activate.
Page 42: Update The Scanner
Internet Explorer 4.0 or newer ● NOTE Before updating, please make sure your network works correctly. Before updating, please make sure you have already created a Foxwell ID. To update your scanner: 1. Double click the desktop icon to launch the application.
Page 43 Figure 9-22 Sample Upgrade Check Screen 6. When Upgrade button is clicked, it begins to download. And you can check the Current Status. If the Current Status shows Downloading, please do not close the update application. T2000 TPMS Service Tool Manual_English_V1.01...
Page 44 7. When all the items are updated, an “All software downloads are successfully installed!” message displays. Please click OK to confirm. Figure 9-24 Sample Update Completed Screen 8. Please click Return to review all the software status. T2000 TPMS Service Tool Manual_English_V1.01...
Page 45 To uninstall a software or all software, select them on the Uninstall tab and click the Uninstall button. And the uninstalled items can be found in the Uninstall screen. Figure 9-27 Sample Software Uninstallation Screen Please click Setting to change the update tool language. T2000 TPMS Service Tool Manual_English_V1.01...
Page 46 Edit and type in the message box and click Confirm. To help us provide better sales, please make sure that the telephone, email and country are correctly entered. Figure 9-29 Sample User Information Screen T2000 TPMS Service Tool Manual_English_V1.01...
