- Page 1 XD1225 INSTALLATION/OWNER'S MANUAL AM/FM/CD Receiver with Auxiliary Input, USB Charging Port and Detachable Face Charge Port...
-
Page 2: Getting Started
XD1225 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
Green (+) Wiring Diagram RCA Cable (sold separately) FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XD1225 uses one 5 amp AGC fuse located in-line. -
Page 4: Control Locations
Auxiliary Input Preset 6 The XD1225 has an easy-to-use interface that provides a rewarding experience, as well as support for your favorite tunes. Audio CD-R and CD-RW disc playback ensures compatibility with your music collection, and the RCA preamp output provides the right connections to expand your system. -
Page 5: General Operation
XD1225 OPERATION General Operation Faceplate Removal Press RELEASE and pull away from the left side to remove. To re-install, insert right side of faceplate first then push left side to secure. Semi-permanent Faceplate Remove trim ring and install supplied #1 x 7/32” Phillips head Installation screw through left side of mounting frame into faceplate. - Page 6 XD1225 OPERATION General Operation Setup Menu Menu Function Options LOUD OFF Loudness Curve LOUD ON FRE USA Tuner Frequency Spacing FRE EU LOC OFF Local/Distance Tuning LOC ON CLOC ON Clock Display CLOC OFF BEEP OFF Beep Confirmation BEEP ON USB Charging Port Audio Press and hold AUDIO/MENU for more than 3 seconds to access the setup menu, then press AUDIO/MENU to cycle through menu options.
-
Page 7: Audio Operation
Seek Tuning Manual Tuning FM Stereo/Mono Band Storing and Recalling Station Presets XD1225 OPERATION Press AUDIO until BAS appears Rotate the volume knob left/right to adjust (-6 minimum / 6 maximum) Press AUDIO until TRE appears Rotate the volume knob left/right to adjust (-6 minimum / 6 maximum) Press AUDIO until BAL appears Rotate the volume knob left/right to adjust... -
Page 8: Cd Player Operation
XD1225 OPERATION CD Player Operation Insert CD Eject CD Track Select Fast Forward and Reverse Pause Intro Repeat Random CD-R/CD-RW Compatibility With the label facing up, insert a standard size CD into the CD slot. The CD will automatically begin playback. Press the EJECT button to stop and eject the CD. -
Page 9: Troubleshooting
Error Code ER-1 appears on display Disc error ER-2 appears on display Mechanism error or disc is in upside down ER-3 appears on display Servo error XD1225 OPERATION Troubleshooting Cause Check connections for proper voltage (11~16VDC) Check connection to ground Replace fuse... -
Page 10: Limited One Year Warranty
Dual Electronics Corp. agrees, at our option, during the warranty period, to repair any defect in material or workmanship or to furnish an equal... -
Page 11: Fcc Compliance
Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. XD1225 OPERATION FCC Compliance... -
Page 12: Specifications
Frequency response: 80Hz-2kHz General Speaker output impedance: 4~8 ohms Fuse: 5 amp AGC Dimensions: 7" x 7" x 2" (178 x 178 x 51 mm) Design and specifications subject to change without notice. CEA-2006 Power Standard Specifications (reference: 14.4VDC +/- 0.2V, 20Hz~20kHz) Dual Electronics Corp. Toll Free: 1-866-382-5476 www.dualav.com ©2010 Dual Electronics Corp. All rights reserved. NSA0710-V02...
