Draytek Vigor2100 Quick Start Manual page 11

1.3.2 Vigor2100G
LED Status
on
WLAN
blinking
E-mail blinking
orange
WAN green
blinking
on
Firewall
blinking
ACT (Activity) on
orange
green
LAN
)
(P1, P2, P3, P4
blinking
Interface Description
Connect the included power adapter to the power outlet.
PWR
WAN Connect the Cable/ADSL modem to access the Internet.
Restore the default settings. Usage: Turn on the router (ACT LED is
blinking), press the hole and keep for more than 5 seconds. When the ACT
Factory Reset
LED begins to blink rapidly, release the button. Then the router will restart
with the factory default configuration.
P1, P2, P3, P4 Connect to the local network devices.
Explanation
The Wireless LAN function is active.
Data packets are transmitted over Wireless LAN.
When detecting one or more user-defined e-mails existing on
mail server.
A normal 10Mbps connection is through its corresponding port.
A normal 100Mbps connection is through its corresponding
port.
Ethernet packets are transmitting.
The firewall function is active.
When encountering DoS attacks.
The router is powered on and running properly.
A normal 10Mbps connection is through its corresponding port.
A normal 100Mbps connection is through its corresponding
port.
Ethernet packets are transmitting.
5
