Summary of Contents for Artopex downtown

  • Page 1 Installation guide Update : August 2016...
  • Page 2 Installation guide...
  • Page 3: Table Of Contents

    Installation of D.C. on table with architectural base 9 Installation of D.C. on table with metal leg 10 Privacy screens Legs 11 Bracket 11 Shelf 11 Mobile panels Legs 12 Communication panel 12 Panel with the Downtown Connection system 13 Installation of D.C. in the mobile panel 13...
  • Page 4: Seating

    Installation guide SEATING Ganging bracket for seating Armrest Step 1 : Step 1 : Press the back of the armrest to the backrest of the seating. Ensure that you have parts "A" and ''B'' . Step 2 : Step 2 : Screw the metal plate to the side of the seating.
  • Page 5: Bistro Tables

    Installation guide TABLES Bistro table 29''H collaborative work tables with architectural base and laminate gable Step 1 : Step 1 : Place all parts upside down to acces the underside. Place all parts upside down to acces the underside.
  • Page 6: Mediacom Bistro Tables

    Install the vertical cable conduit : Before installing the work surface, if it applicable, install the - Using the pre-drilled holes, attach the screws into the Downtown Connection (M8) in the architectural base, refer to technical panel by screwing lightly. pages 8 and 9.
  • Page 7: Mediacom Tables With Metal Leg

    Finishing profiles are used to conceal electrical cables and Step 4 : the monitor support brackets. The profiles are installed on If it applicable, install the Downtown Connection (M8). Refer to the technical panel of a Mediacom table, on either side of the pages 8 and 10.
  • Page 8: Downtown Connection

    Monitor cable Step 5 : Screw the black metal plate provided by Artopex to the eletronic box. Blue plastic lock Screw the blue lock in the electronic box and fix it with a tie wrap.
  • Page 9: Installation Of D.c. On Table With Architectural Base

    Installation guide DOWNTOWN CONNECTION Installation of Downtown Connection under a Mediacom table with architectural base Step 1 : Step 5 (continued) : ATTENTION - Install Downtown Connection before installing the - Electrical cable (orange) surface. Attach the transformer to the interior of the architectural base using the bracket included (no pre-drilled holes).
  • Page 10: Installation Of D.c. On Table With Metal Leg

    Installation guide DOWNTOWN CONNECTION Installation of Downtown Connection under a Mediacom table with metal leg or Bistro Mediacom table Cable fastener Power bar Metal support Grommet Electronic box with connections Transformer Cable access module Step 3 : Step 1 :...
  • Page 11: Legs

    Installation guide DOWNTOWN CONNECTION PRIVACY SCREEN Legs Step 5 : The installation of legs is the same for all privacy screens. Assemble the cable access module. - Insert the 4 HDMI data sharing cables into the cable access module and keep them in place using the black plastic rings included.
  • Page 12: Mobile Panels

    Install the metal shelf. Screw the shelf using the pre-drilled holes in the metal structure. Then, screw the cable conduit under the shelf. Marker board Communication Panel with Downtown panel Connection system Step 1 : Attach the shelf Attach the cable conduit...
  • Page 13: Panel With The Downtown Connection System

    Cable access module Handle Removable laminate panel Step 2 : Install the electrical outlets. Refer to the following section for Downtown Connection system. Place the electric outlet in this hole and plug it into Transformer Cable separator (welded) the power bar.
