  • Page 1 Top Wheel Mix & Match Top Wheel Mix & Match 1MANUAL749 Rev12...
  • Page 3 Do not make additional copies of this manual or electronically transmit it in any form ® whatsoever, in whole or in part, without the prior written permission of Belanger, Inc. The registered trademarks used in this document are the property of their respective owners. The use of such trademarks is ®...
  • Page 4 Changed Gearbox Assembly number from 1GEABX-AS985 to 10/09/2020 112285 (per ECN #5131) Back Updated Back Cover with correct phone number Cover Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 5: Table Of Contents

    Utility Connections ..............................43 Water Feeds ..................................43 Electric Drive Motor Feed ..............................44 Hydraulic Drive Motor Feed (North American Option) ......................45 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 6 Auto Retract Photo Eye Tree ............................... 71 Retract Air Panel .................................. 72 Appendix A: CE Information ..................73 Appendix B: De-Commissioning (Dismantling and Disposal) ........ 74 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 7: Belanger Incorporated Limited Warranty

    PURPOSE CONTAINED IN THE UNIFORM COMMERCIAL CODE – SALES ARE EXPRESSLY DISCLAIMED. Copyright ©2013 by Belanger, Inc. All rights reserved. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system, except as may be expressly permitted by the 1976 Copyright Act.

  • Page 8: Introduction

    !!IMPORTANT!! Important information that has more impact than a note-not related to injury. NOTE: General and/or helpful information-not related to injury or damage. Helpful tips. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 9 WARNING – BE AWARE OF FOREIGN OBJECTS IN THE AREA SURROUNDING A ROTATING PIECE OF EQUIPMENT. OBJECTS MAY BECOME TANGLED WITH EQUIPMENT AND COULD RESULT IN SERIOUS INJURY OR DEATH. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 10 THE PIVOTING SECTION IN PLACE OR HAVE SOMEONE ASSIST IN KEEPING IT IN PLACE UNTIL THE WEIGHTS HAVE BEEN BOLTED DOWN! Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 11 DO NOT USE TABLES, CHAIRS, OR OTHER NON-APPROVED CLIMBING EQUIPMENT OTHER THAN AS STATED HEREIN. CAUTION – ALWAYS WEAR SAFETY GLASSES WHEN PERFORMING MAINTENANCE ON ANY EQUIPMENT. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 12: Operational Warning

    MSDS (Material Safety Data Sheet) should be obtained from the chemical supplier before using any chemical formulation. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 13: Environmental Parameters

    Instruct personnel not to work on wash unless the entrance is blocked from vehicles entering, this is in addition to all other safety precautions. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 14: Do's And Do Not's

    Periodically check all system stop circuits are functional. Table 1 Recommended General Practices to Do and Not Do when Installing, Maintaining, and/or Servicing Belanger® Equipment. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 15: Description Of Top Wheel

    Read through the entire manual to familiarize you with the Top Wheel before installation. When installation is completed, you will want to keep this manual as a guide to proper maintenance. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 16: Before You Get Started

    Notify your local distributor or Belanger, Inc. immediately If shipment is determined damaged or incomplete. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 17: Specifications

    AT 900 PSI (62.1 BAR) WHILE LOADED AGAINST VEHICLE. PLEASE VERIFY NOTE: YOUR SYSTEMS CAPABILITY TO MEET THESE SETTINGS WHILE RUNNING A VEHICLE PRIOR TO INSTALLING PIECE OF EQUIPMENT. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 18: General Dimensions

    Mix and Match Specifications General Dimensions 114” (2.90 m) 146” (3.71 140” (3.56 m) When in Retract Position 146” (3.71 m) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 19: Installation

    Note: Always keep the long side of the Neo-Tex™ on the same side to assist in wheel balance. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 20: Neo-Tex™ Hub Assembly

    Slide in the Neo-Tex™ pieces using every other slot on the hub; spin the hub as needed until there are 15 pieces around the hub. Install Row 1 Install Clamp Driver Side Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 21 Snug the locking collar against the wash clips as shown in the following images. Install Row 3 Install Row 4 Install Row 5 Install Row 6 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 22 6) Locate the supplied Hub Guard and fasteners. Secure them to both ends of the Hub Assembly as shown below. Hub Guard and Fasteners (typical) Before After Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 23: Whisper Wheel Hub Overview (North American Option)

    • 4 - 1WASHR-FL330 go into the (1/4” flat washers) blot- • 2 - 1NUT-LC201 spaces of (1/4” Nylock™ nuts) the hub. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 24: Whisper Wheel Hub Assembly (North American Option)

    4) Locate the supplied Hub Guard and fasteners. Secure them to both ends of the Hub Assembly as shown below. Hub Guard Fasteners (typical) Before After Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 25: Frame Assembly

    (89 mm) bolt from the accessory box. This will prevent the bearing from spinning during the torque process. Remove the Insert the 1” (25.4 mm) 3-1/2” bolt and the (89 mm) lock washer bolt Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 26 7) Remove the 3-1/2” (89 mm) bolt and replace the original 1” (25.4 mm) bolt and tighten it into place. Reinstall 1” bolt Remove and the lock 3-1/2” bolt washer Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 27: Securing Drive Shaft And Hydraulic Motor Assembly To The Driver Side Arm

    3/4” flat washer 1/2” thick spacer 3/4” lock washer Motor/Torque Plate and Shaft Assembly 3/4-16 x 1-1/2” bolt (Apply “Red Loctite® 271) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 28 Bolts should be flush on the inside of the beams (typical) 2” from inside edge of bolt to outside edge of mounting plate Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 29: Securing The Arms To The Hub

    Secure the arms to the hub Driver Side Passenger Side You may have to pivot the arms to access the bolt holes Direction of Travel Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 30: Installing The Crossbeam

    Once square, tighten all bolts. Cross Beam NOTE: Spray Nozzles are to face the hub Secure the Crossbeam to the Legs Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 31: Attaching The Legs

    You may have to pivot the legs to access the bolt holes Secure the driver side legs to the arms Secure the passenger side legs to the arms Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 32: Tunnel Placement Overview

    Note: The 45” (1.14 m) dimension is taken from the outside driver side leg base plate, to the inside guide rail. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 33: Erecting The Frame

    4) Measure distance between the upper and lower legs. Make sure the frame is square and lag the passenger side leg to the floor. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 34: Motor/Gearbox Installation: Electric Drive Neo-Tex™/ Whisper Media

    Torque Plate Studs Flat Washers 3) When assembled it should appear as one of the images below. Retainer Pins Standard Motor Cover Option Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 35 4) After the motor has been wired, secure the lid onto the plastic motor cover using the supplied self-tapping screws as shown below. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 36: Motor/Gearbox Installation: Electric Drive Brush Wheel

    16 x 1-1/4” bolts with lock washers. Before After 4) Tighten the setscrews of the gearbox using a 5/32” (4 mm) Allen wrench. Setscrews located here Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 37: Posi-Stops Installation

    Stop Block. Note: Make sure that both arms make contact with the rubber stops. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 38: Shock Assembly

    1) Secure the Shock Assembly back onto the driver side Arm Assembly. 2) Secure the unattached end of the shock to the clevis as shown below. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 39: Auto Retract Option Installation (If Applicable)

    60” (1.52 m) from floor Both lower Photo Eyes to be set at 40” (1.02 m) from floor Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 40: Parts Identification

    3) Screw the Sensitivity Reducer onto the upper Receiver on the passenger side as shown below. Photo Eye and Sensitivity Reducer Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 41: Wiring For Optional Auto Retract

    Input Brown + 340 ( 24VDC is ON and remains ON Blue - 338 ( DC COM Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 42: Air Panel Installation And Photo-Eye Utility Connection (If Applicable)

    2) Run 3/8” (9.52 mm) poly-flow airline from the regulator of the air panel to the fitting on the Retract Cylinder as shown below. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 43: Counterweight Installation

    2) Use the Counterweight Configuration Chart to determine the amount of weight required to balance your Top Wheel, and the bolts required to hold the weights in place. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 44 Drill two more 1/4” (6.35 mm) holes 120º F (49º C) in each direction from the top hole. 5/8” (15.88 mm) Overhead View Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 45 9) In a situation where there is an arm that requires no Counterweights, place the Rear Cover on the back of the arm and tighten down with the provided 1/2-13 x 1” bolts and the flat washers. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 46: End Caps

    Passenger Side (Before) Passenger Side (After) Driver Side (Before) Driver Side (After) Install Cap Here Install Cap Here Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 47: Utility Connections

    2) Install 3/4” (19 mm) water hose to spray manifold located in the cross beam using the supplied Hose Clamp as shown below. Hose Clamp Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 48: Electric Drive Motor Feed

    For electric drive be sure to insert the socket head fasteners into the top and third holes as shown below. Use these holes for electric drive Clamp Mounts Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 49: Hydraulic Drive Motor Feed (North American Option)

    1) Locate the two 1/2” MJIC Straight Fittings and two 1/2” MJIC Elbows from the Accessory Box. Apply liquid Teflon to all threads of the fittings and secure into place as shown below. Before After Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 50 Use these holes for electric drive Clamp Mounts Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 51: Startup

    WARNING – BE AWARE OF THE AREA SURROUNDING A ROTATING PIECE OF EQUIPMENT. OBJECTS MAY BECOME TANGLED WITH EQUIPMENT AND COULD RESULT IN SERIOUS INJURY OR DEATH. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 52: Adjusting Internal Counterweights

    • Flush water through the manifold to remove any debris • Install the nozzles on manifold • Run a test vehicle Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 53: Maintenance

    Wash component down with a good degrimer such as laundry detergent and hot water. • Check wash material for wear. Replace if necessary. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 54: General Repairs

    3/4” (19 mm) flat washer 3/4” (19 mm) lock washer 1/2” (12.7 mm) thick spacer 3/4-16 x 1-1/2” bolt (Apply red Loctite® 271™) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 55 (25.4 mm) bolt and lock washer Follow this same assembly process when replacing or performing maintenance to the drive shaft Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 56: Torque Plate And Electric Motor Replacement

    The cord grip will need to be loosened or removed so that the wiring can be pulled down through the cover base if equipped. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 57 10) Using a 5 mm Allen wrench; remove the four fasteners to separate the torque plate and mounting ring from the gearbox to expose the mounting holes on the gearbox. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 58 3) Once the key and keyway are aligned, lower the gearbox onto the torque bolts to its resting position. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 59 9) Once the motor gearbox unit is properly secured into position, power can be turned back 10) Verify wheel rotation prior to running any test vehicle through the system. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 60: Neo-Tex™ Fill Replacement

    Yellow 41” x 10” x 1/8” thick 6342 6343 6345 6344 7414 6405 (104.1 cm x 25.4 cm x 3.17 mm) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 61 Slide in the Neo-Tex™ pieces using every other slot on the hub; spin the hub as needed until there are 15 pieces around the hub. Install Clamp Install Row 1 Driver Side Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 62 Install Row 3 Install Row 4 Install Row 5 Install Row 6 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 63 8) Attach the Hub Guard and fasteners to both ends of the hub as shown below. Hub Guard and Fasteners (typical) Before After Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 64: Whisper Wheel™ Fill Replacement

    • 2 - 1FSTNR-HH081 (1/4-20 x 1-1/2” bolts) • 4 - 1WASHR-FL332 (1/4” flat washers) • 2 - 1NUT-LC210 (1/4” Nylock™ nuts) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 65: Replacing Whisper Wheel™ Cleaning Material

    Whisper Wheel to hold the material in place as shown below. Slide final collar tight to Whisper Wheel™ Pack Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
  • Page 66 4) Attach the Hub Guard and fasteners to both ends of the hub as shown below. Hub Guard Fasteners (typical) Before After Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 67: Exploded Parts

    4-Bolt 7546: Drive Adaptor (5-Bolt Hub) 7547: Idler Adaptor (4-Bolt Hub) 7545 Uses: Uses: Uses: 1FSTNR-BH510 (4) 1FSTNR-BH510 (4) 1FSTNR-BH510 (6) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 68: Nylon Brush Hub Assembly

    See previous page for fastener information on the bearings Leg Assemblies 102912: Passenger Side Leg Assembly 102901: Driver Side Leg Weldment 102902: Passenger Side Leg Weldment 1BSHNG364 (2) Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 69: Passenger Side Arm Assembly

    25 lb. (11.3 kg) 1FSTNR-HH594: 3-1/2” (89 mm) weight 1FSTNR-HH630: 5” (127 mm) 1FSTNR-HH666: 6” (152 mm) Weight Cover 1PLSTC-CR470 (includes both pieces) 1CLIP-PL250 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 70: Driver Side Arm Assembly

    6845: Sleeve 1FSTNR-HH288: 4 pieces 1NUT-LC220 1WASHR-LC291: 4 pieces 1SHOCK875 6838 1NUT-LC220 1FSTNR-HH811 1FSTNR-HH918 1WASHR-FL830 100092 1FSTNR-HH811 Hydraulic Hose Fittings 1ELBOW-ST539 1MCONC-ST250 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 71: Drive Assembly (Hydraulic) (North American Option)

    1WASHR-LC291 (4) 1WASHR-FL810 Key included with Gearbox 1GEABX295 1WASHR-ST375 (4) 6841: 1/2” Spacer 1SHAFT830 1FSTNR-HH261 (4) Standard Electric Drive Assembly Complete Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 72: Electric Drive Assembly (1Hp; Neo-Tex™ / Whisper Wheel)

    Motorvario Electric Drive Assembly Complete Black: PLSTC-CV080 Blue: PLSTC-CV082 Green: PLSTC-CV088 Gray: PLSTC-CV092 Orange: PLSTC-CV086 Red: PLSTC-CV084 Yellow: PLSTC-CV090 1RETNR129 1FSTNR-PH040 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 73: Cross Beam Assembly: 102909 Complete

    1ELBOW-PL915 102906: Water Manifold Weldment Spray Nozzle Assembly Complete 1NOZZL972: Cap and Gasket 1NOZZL-FJ116: Nozzle Tip 1MCONC-SS025: Extension 1NOZZL993: Nozzle Body Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 74: Posi-Stop Parts

    1FSTNR-SB125 1WASHR-FL415 1FSTNR-SB125 Clamps used to secure Cylinder Hose to Leg Assembly 1CLAMP294: 2 pieces 1FSTNR-SH384: 2 pieces 1WASHR-FL332: 2 pieces Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 75: Auto Retract Photo Eye Tree

    When replacing a Photo-Eye be sure to position the clear LED indicators toward the closest end to make verification of operation easier. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 76: Retract Air Panel

    1MADAP-BR600: 2 pieces 1ELBOW-PL666 1FSTNR-SH177: 2 pieces 2501 1WASHR-LC115: 2 pieces 2529 1VALVE-EL370 1FSTNR-SH059: 2 pieces 3699 1AIRLN250 1GAUGE500 1RGLTR175 1ELBOW-PL535 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 77: Appendix A: Ce Information

    Gyro Wrap™ 1MANUL247 Quad Wave Mitter™ 1MANUL633 Low Side Washer 1MANUL858 Top Wheel 1MANUL749 DuraScrubber® 1MANUL080 Chameleon® Arch 1MANUL526 Air Cannon™ 1MANUL008 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...

  • Page 78: Appendix B: De-Commissioning (Dismantling And Disposal)

    ENVIRONMENTAL LAW – DO NOT DISPOSE OF BY ADDING TO THE MUNICIPAL WAST STREAM. METAL/OTHER PARTS OF THE SYSTEM: MUST BE RECYCLED AS REQUIRED BY LOCAL ENVIRONMENTAL LAW. Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL749...
