Temperature Range; Mechanical Specifications - Trackunit TU600-x Short Manual

TU600-x

Temperature range

In active running mode
Storage

Mechanical specifications

Length
Width
Height
Cable length
Environmental class
Weight
Short Guide TU600-x v0.2, January 2020, ©Trackunit 2020
-20ºC to +55ºC/60ºC
Limited by the Li-Ion backup battery when the unit is either machinery or
battery powered.
-40ºC to +70ºC
Shorter battery lifetime must be expected when storage and operation
occur at extreme temperatures.
122,3 mm (4.8 in.)
45.5 mm (1.8 in.) (50,1 mm incl. cradle) (1.9 in.)
17.9 mm (0.7 in.) (22,7 mm incl. cradle) (0.9 in.)
170 cm (5.6 ft.)
IP67 (With HW Shield IP66k & IP69k – PN. 7402.9551 and 7402.9552)
66 g (excluding cable) (2.3 oz.)
12
