- Page 1 TU600-X TU600-X Technical Manual Version 1.0, December 2019...
-
Page 2: Table Of Contents
SMS commands for output control ................. 20 Safety precautions......................20 Warranty ...................... 20 Technical Assistance/Support and spare parts ..........20 Minimum Information Required for Technical Assistance ..........21 Return Merchandise Authorization - RMA ..............21 Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 2... - Page 3 Australia and New Zealand .................... 27 Japan ..........................28 Countries that are exempted for certification ..............28 Environmental compliance ..................... 29 CE marking ........................31 PTCRB certification for interoperability with mobile networks......... 31 Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 3...
- Page 4 (ii) the Product is not modified or misused. This Product countries. All other trademarks are the property of their Limited Warranty shall not apply to, and Trackunit shall not be respective owners. responsible for, defects or performance problems resulting from:...
- Page 5 GPS, GSM 900MHz/1800MHz and LTE M1/NB IoT thereto) contains valuable trade secrets and is proprietary to 700MHz/800MHz/1800MHz/2100MHz Radio Equipment and Trackunit and its suppliers. To the greatest extent permitted by Systems). law, such embedded software/firmware may not be modified, copied, disassembled, decompiled or reverse engineered.
- Page 6 TU600-X US and Canada certificates: FCC ID: ZMF-TU600 9746A-TU600 EU certificate: CE mark by EU-Tec certificate: T818625L-01-TEC Australia/New Zealand SDOC approval: RCM mark Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 6...
-
Page 7: Introduction
This manual describes how to set up, configure, install, operate, and troubleshoot the product. Even if you have used other GSM, LTE M1/NB IOT or Global Positioning System (GPS) products before, Trackunit recommends that you spend some time reading this manual to learn about the special features of this product. -
Page 8: Interference
Use only Trackunit approved accessories or batteries. Do not connect incompatible products. The battery package is a Trackunit design, no other battery designs are compatible with the battery holder of the TU600-X. There is risk of explosion or fire if an incorrect type replacement battery is forced into the battery holder as contact may generate a short circuit. -
Page 9: Electronic Devices
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding the vehicle. Also consult the manufacturer of any equipment that has been added to the vehicle. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 9... -
Page 10: Posted Facilities
(8”) inches (20 cm) is to be maintained between the TU600-X and any persons’ body. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site at www.ctia.org. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 10... -
Page 11: Battery Safety Information
* The risks are: No leakage, No venting, No disassembly, No rupture or No fire. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 11... -
Page 12: Delivered Standard Content
The TU600-X unit takes advantage of both technologies by automatically selecting GPRS wherever such service is available, while relying upon SMS text messages for configuration purpose only. This helps minimize recurring communication costs while allowing the greatest coverage possible. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 12... -
Page 13: Use Location - Children Not Likely To Be Present
The local sales office will be able to inform you about the obligations that you have in relation to the insurance company and how to act in relation to the alarm center while the units are covered by the insurance. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 13... -
Page 14: Connections
TU600 is equipped with a built-in CAN Controller. Protocols supported: SAE J1939 and CANopen. The CAN interface is Fully Compliant with CAN 2.0 Part A and 2.0 Part B. 8 independent message objects (mailboxes) are implemented, and Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 14... -
Page 15: Installing The Tu600-X As To Surpass The Main Switch On The Machine
TU600 is physically installed. In addition to the use case described above the TU600 can also be requested to passive scan for BLE advertisements and thereby enable assert tracking. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 15... -
Page 16: Functionality Check
TU600-X Functionality check Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 16... -
Page 17: Verify My Trackunit
TU600-X “Verify my Trackunit” In order to control if the installation of the TU600-X unit has been done correctly, it is possible to use the “Verify my Trackunit” tool. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 17... -
Page 18: Troubleshooting
“Installing the GPS signal unit” chapter. If the machine/vehicles are located inside a building, please move the machine/vehicle outside a try again. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 18... -
Page 19: Installation Of The Digital Output
One application example for the “Usable contact function controlled by the TU600-X” signals shown in the figure above could be a “Start Relay”, blocking function, for preventing unauthorized use of the moving machinery and construction machine or vehicle outside normal working hours etc. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 19... -
Page 20: Sms Commands For Output Control
The invoice act as the proof of warranty, so please keep it as reference for any warranty complaints. Technical Assistance/Support and spare parts Trackunit A/S offers technical assistance to all our customers about the use, installation, insurance and spare parts: If you have a problem and cannot find the information you need in the product documentation, please contact Trackunit A/S. -
Page 21: Minimum Information Required For Technical Assistance
TU600-X For mounting the Trackunit TU600-x in harsh environment, not covered by the compliance statements or areas where pressure cleaning is required the Trackunit HW shield PN 7402.9551 is required for protective mounting. Please order at Trackunit A/S. Recommended fuse holders and fuses up to 48V supply voltages (Can be ordered at Trackunit A/S): a. -
Page 22: Specifications
(If the temperature exceeds this range the battery supply voltage is disabled, and the battery put into internal storage mode. Due to a small internal self-heating during operation this may occur at external temperatures between 55°C - 60°C.) Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 22... -
Page 23: External Temperature Ranges
B19: TX 830-844.9 MHz, RX 875-889.9 MHz B20: TX 832-862 MHz, RX 791-821 MHz. B26: TX 814-848.9 MHz, RX 859-893.9 MHz B28: TX 703-748 MHz, RX 758-803 MHz Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 23... - Page 24 B39: TX 1880-1920 MHz, RX 1180-1920 MHz The marked bands B12/B13 are denoted LTE 700 MHz band lower and upper part. The bands B18/B19 are denoted LTE 800 band lower and upper part for Japan. Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 24...
-
Page 25: Mechanical Specifications
18 mm (23 mm incl. mounting cradle) Cable length: 170 - 180 cm Environmental class: IP68 Enclosure material: Non-flammable PP casing and ABS cable connector lid. Weight: 65 g (excluding the cable) Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 25... -
Page 26: Approvals And Certificates
Statements according to CFR 47 Part 15.21: Changes or modifications made to this equipment not expressly approved by Trackunit may void the FCC authorization to operate this equipment. Statements according to CFR 47 Part 2.1091 and OET bulletin 65 / RSS-102: With respect to radiofrequency radiation exposure Information it is declared that this equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. -
Page 27: Automotive, Off-Road Vehicles, Machinery Etc
The TU600-X product complies with the requirements of the relevant ACMA Standards made under the Radiocommunications Act 1992 and the Telecommunications Act 1997, by the Supplier's Declaration of Conformity (SDOC). These Standards are referenced in Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 27... -
Page 28: Japan
The declarations are available upon request to Trackunit A/S. For Chile a label must be applied in the user manual for compliance with the radio and EMC law: Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 28... -
Page 29: Environmental Compliance
NOTE B: The housing not designed to withstand high pressure cleaning. Only use the TU600 when mounted inside the designated Trackunit protection cap (Can be ordered at Trackunit A/S) in mounting areas where high pressure cleaning is common procedure. Trackunit TU600-X, Technical Manual v1.0, December 2019... - Page 30 TU600-X Environmental protection without HW shield: Environmental protection with use of HW shield: Trackunit TU600-X, Technical Manual v1.0, December 2019 Page 30...
-
Page 31: Ce Marking
TU600-X CE marking We, Trackunit A/S hereby declare that the TU600-X product complies with the essential requirements of the RED Directive 2014/53/EU as stated by the EU Declaration of Conformity. EU Certificate and Declaration of conformity (DOC) statements can be downloaded from the Trackunit website: http://www.trackunit.com/en/trackunit/approvals/approvals.htm...
