Spot
Orientation suggestions
Vertical installation
Horizontal installation
For better antenna
Antenna is placed on
performance place the
the top right corner.
device facing up. Use
Use sticker on the
sticker on the backside
backside as indicator
as indicator of the
of the left side.
bottom side.
Practical advice
Phone number and
Serial number is
unit serial number is
located on the back of
also located on the lid
the device.
of the box.
Technical assistance
Find your local support at
www.trackunit.com/support/
Please have unit serial number ready when contacting suppor
Installation instructions
Mount Trackunit Spot
Do NOT install the
using M4 or 5/32 inch
device unit directly
screws that can be
under a layer of metal
found inside the box.
or next to wires.
Use TX20 tool ( 0,6
Nm).
t
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Trackunit Spot
Summary of Contents for Trackunit Spot
-
Page 1: Installation Instructions
Spot Orientation suggestions Installation instructions Vertical installation Horizontal installation Mount Trackunit Spot Do NOT install the For better antenna Antenna is placed on using M4 or 5/32 inch device unit directly performance place the the top right corner. screws that can be under a layer of metal device facing up. - Page 2 The following precautions applies: FCC part 15.21 Notice: • The TU50X-1 SPOT unit is not intended for handheld use or to be worn on the body. Changes or modifications made to this equipment not expressly approved by Trackunit may void the •...
