Installation and
Operating Instructions
Davey Weekender
(XP)
Home Pressure Systems
NOTE: Prior to installation remove the inlet and outlet
pipe transport plugs & associated seals from the
suction and/or discharge ports.
Please pass these instructions on to the operator of this equipment.
Advertisement
Related Manuals for Davey Weekender XP
Summary of Contents for Davey Weekender XP
- Page 1 Installation and Operating Instructions Davey Weekender (XP) Home Pressure Systems NOTE: Prior to installation remove the inlet and outlet pipe transport plugs & associated seals from the suction and/or discharge ports. Please pass these instructions on to the operator of this equipment.
-
Page 2: Choosing A Site
Operating Instructions. Read these in their entirety before switching on this pump. If you are uncertain as to any of these Installation and Operating Instructions please contact your Davey dealer or the appropriate Davey office as listed on the back of this document. - Page 3 Housing your Davey Pressure System To protect your pressure system from the weather, make sure the pump house is both water proof, frost free and has adequate ventilation. The pump should be horizontally mounted on a firm base allowing for drainage, to avoid damage to flooring etc., that over time may occur from leaking...
- Page 4 1 metre This adjustment should only be carried out by a suitably qualified and authorised person. Your Davey dealer would be happy to assist. 1) Switch off pump and unplug it from power point. 2) Remove pressure switch cap. 3) Turn Adjusting screw, (A) turn anticlockwise.
- Page 5 Where your pressure system is required to discharge through float valves filling tanks, the possibility of excessive cycling may occur. This can be overcome by fitting a larger Davey Supercell pressure tank in place of the Supercell tank supplied. Priming and Operation 1.
-
Page 6: Maintenance
1. Check that tank air charge is 130kPa (19 psi). 2. Rapid cycling may occasionally be caused by float valves filling tanks. This can be overcome by fitting a larger Davey Supercell tank in place of the tank supplied. 3. Leaking taps, float valves etc. Check plumbing. - Page 7 *NOTE: For protection, the Davey pump motor is fitted with an automatic “over temperature” cut-out. Constant tripping of this overload device indicates a problem eg. low voltage at pump, excessive temperature (above 45 C) in pump enclosure. WARNING: When servicing or attending pump, always ensure power is switched off and lead unplugged.
- Page 8 ABN 18 066 327 517 Website: davey.com.au Website: daveynz.co.nz ® Davey is a registered trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017. P/N 402215-1 * Installation and operating instructions are included with the product when purchased new.
