Operating Instructions
WARNING: Failure to follow these instructions and comply with all
applicable codes may cause serious bodily injury and/or property damage.
The installation of this product should be carried out by a person knowledgeable
in swimming pool plumbing requirements following the installation instructions
provided in this manual.
Please pass these instructions on to the operator of this equipment.
SureFlo
Installation and
™
Advertisement
Table of Contents
Related Manuals for Davey SureFlo DSF750
Summary of Contents for Davey SureFlo DSF750
-
Page 1: Operating Instructions
SureFlo ™ Installation and Operating Instructions WARNING: Failure to follow these instructions and comply with all applicable codes may cause serious bodily injury and/or property damage. The installation of this product should be carried out by a person knowledgeable in swimming pool plumbing requirements following the installation instructions provided in this manual. - Page 2 Operating Instructions. Read these in their entirety before switching on this pump. If you are uncertain as to any of these Installation and Operating Instructions please contact your Davey dealer or the appropriate Davey office as listed on the back of this document. Your Davey SureFlo Pool Pump Congratulations on your purchase of a quality product from the Davey range of Pool equipment.
- Page 3 Davey SureFlo Pool Pump – Hydraulic Performance: TOTAL HEAD (m) DSF1350 DSF1100 DSF900 DSF750 100 150 250 300 FLOW (lpm) Power (P Power (P Net Weight Model Amps (L/min) (kg) DSF750 12.5 0.75 0.55 0.75 10.0 DSF900 15.0 0.65 0.85 10.5...
-
Page 4: Weather Protection
(Please refer to your local statutes and regulations for AS/NZ 3000 Wiring standards). Davey SureFlo pool pumps are suitable for connection to a nominal 240 volt 50Hz power supply and are equipped with a flex lead and 3 pin plug. If a power outlet is not available within 3 metres of the pump, a 3 pin power point in a safe, dry place may need to be provided by an electrician. -
Page 5: Typical Installation Diagram
Typical installation diagram Vacuum hose Vacuum head Water pump Sand filter Dimensions 205.5 Pipe Connection A set of self-aligning barrel unions are provided for connecting to the piping from the pool. The pumps are designed to accept the following PVC pipes by fitting the pipe to either the inside or a pipe socket to the outside of the union tail. -
Page 6: Starting The Pump
Starting the Pump To operate efficiently and prevent pump damage there must be a free flow of water to and from the pump. Before starting ensure that: • All pipework is correctly sealed. • The pool water level is at the correct height. •... -
Page 7: Pump Operation
Never run pump dry. Running the pump with no water may damage the mechanical seals, causing leakage and flooding. Dry running damage and associated damage is not covered under warranty. Davey SureFlo pool pumps incorporate self-resetting thermal overload, reducing potential damage. -
Page 8: Troubleshooting
4. Motor is burnt out – burning smell is evident. Replacement is required. If you are unable to resolve any installation or operation difficulties with your Davey SureFlo pool pump, contact the supplier from whom the pump was purchased or you’re nearest Authorised Davey Pool Equipment Service Centre. -
Page 9: Water Quality
4. Move the pipework with the barrel unions attached until the pump can be pulled clear. NOTE: When making any enquiries about your Davey SureFlo pool pump be certain to quote the model number from the nameplate located on motor. - Page 10 POWER CONNECTIONS AND WIRING MUST BE CARRIED OUT BY AN AUTHORISED ELECTRICIAN. WARNING! Pump suction is hazardous and can trap and drown or disembowel bathers. Do not block suction. Do not use or operate swimming pools if a suction cover is broken, missing or loose. Two suction covers and inlets must be provided into every pump to avoid suction entrapment.
-
