Telco Sensors Space Scan Series User Manual

SS02 - ANN-NNN - USER MANUAL
Space Scan Series
Photoelectric measurement light curtains
Product Data
Electrical Data
Supply voltage
Max. Voltage ripple
Current consumption
Reverse polarity protected
Short circuit protected
Environmental Data
Light immunity @5º incidence
Temperature, operation
Sealing class
Marking
Available Models
Model
SST 01-10-xxx-xxx-05-H-1D1-0.5-J5
Transmitter SST 01-10-xxx-xxx-10-H-1D1-0.5-J5
SST 01-10-xxx-xxx-20-H-1D1-0.5-J5
SSR 02-10-xxx-xxx-05-H-ANN-NNN-0.5-J12
Receiver SSR 02-10-xxx-xxx-10-H-ANN-NNN-0.5-J12
SSR 02-10-xxx-xxx-20-H-ANN-NNN-0.5-J12
Connection
Wiring Diagram ANN-NNN
5 pin, M12
SST 5 pole M12 male connector
Transmitter Model
SST 01-10-xxx-xxx-xx-H-1D1-0.5-J5
Wiring diagram ANN-NNN
SSR02 and PC connection
To setup or adjust a SS02 it is required to use the Telco Space Scan Terminal software together with an RS485 data link.
Website: www.telcosensors.com
E-Mail: info@telcosensors.com
Made in Denmark
SST (Transmitter) SSR (Receiver)
18 — 30 V dc
15 % (within supply range)
100 mA (RMS) 75 mA
Yes
Yes
> 100.000 lux
-30 to + 60 ºC
IP 67
Beam spacing
5 mm
10 mm
20 mm
5 mm
10 mm
20 mm
8 pin, M12
SSR 8 pole M12 male connector
Black wire Black wire
connected to ( - ) not connected connected to ( + )
not transmitting transmitting
!
This product is not a safety system and must not be used as such.
It is not designed for personnel safety applications, and must not be used
as a stand alone personnel safety system.
EN
Installation & Adjustments
Installation
The light curtain is configured by the PC program 'Telco Space Scan Terminal', described in
the following pages. Before using it, check the power supply complies with electrical data.
1 Mount the transmitter (SST) and receiver (SSR) facing each other and correctly aligned.
Wire the sensor according to the wiring diagram.
Notice that the pin 2 on the SSR and the pin 3 on SST (blue wires) must be connected
2
together to a common GND ( — ).
Make sure the SSR output load does not exceed 100 mA.
3 Check for correct wiring before turning power on.
When the power on indicator (green LED) on SSR and SST is on, the system is
4
operating.
Sensing Range
The position of the receiver and transmitter must not be changed after power-up. The
5
light curtain is only intended for static applications.
10 m
SST Test Input
The transmitter SST can be externally disabled and enabled via the black control wire for test
0.5 m — 10 m
purposes. When the transmitter is disabled the action of the receiver corresponds to breaking
all beams.
Indicators
SSR
SSR
SSR & SST
Troubleshooting
Probable Reason
1. Symptom: Status indicator (Red LED) on SSR is constant on.
SST has no power.
SST & SSR white, grey and blue wires are
not connected correctly.
2. Symptom: Output indicator (Yellow LED) on SSR is flashing.
Severe electrical interference.
Severe ambient light.
Black wire
Cross talk from another light curtain or
transmitting
photo sensor
Cross talk from a nearby HF strip light
3. Symptom: Digital outputs do not response when IR beams are obstructed.
One or more beams are blocked or the
rails are out of sensing range.
The test input on SST is activated
Outputs are not configured for simple
detection of obstructions
Warning
tel
Red LED Status indicator
Yellow LED Detection Indicator
Green LED Power on indicator
Corrective Action
Check supply and supply cable to the SST
Connect the wires.
Separate SSR and SST supply cable from high
voltage cables.
Swap position of SSR and SST.
Swap position of SSR and SST.
Swap position of SSR and SST or remove the
strip light.
Remove obstruction or reduce the distance
between the rails.
Remove SST pin 4 (black wire) from ground.
If needed factory reset the SSR using the
System Information page in the PC program
'Telco Space Scan Terminal'
V 1.26 Part Number: L40-0666220750
Telco A/S reserves the right to make changes without prior notice
January 2015 edition
Page 1 of 4
