EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in damage to the
product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not in-
tended for use by children without direct adult supervision. Do not use with incompatible compo-
nents or alter this product in any way outside of the instructions provided by Gustav Staufenbiel
GmbH. This manual contains instructions for safety, operation and maintenance. It is essential to
read and follow all the instructions and warnings in the manual, prior to assembly, setup or use,
in order to operate correctly and avoid damage or serious injury.
As the user of this product, you are solely responsible for operating in a manner that does not
endanger yourself and others or result damage to the product or the property of others. This mo-
del is controlled by a radio signal subject to interference from many sources outside your control.
This interference can cause momentary loss of control so it is advisable to always keep a safe
distance in all directions around your model, as this margin will help avoid collisions or injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
• A lways keep a safe distance in all directions around your model to avoid collisions or injury.
This model is controlled by a radio signal subject to interference from many sources outside
your control. Interference can cause momentary loss of control.
• Always keep aircraft in sight and under control.
• Always operate your model in an open area away from cars, traffi c or people.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate the model in the street or in populated areas for any reason.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate your model with low transmitter batteries.
• Always use fully charged batteries.
• Always remove batteries after use.
• Always let parts cool after use before touching.
• Carefully follow the directions and warnings for this and any optional support equipment
(chargers, rechargeable battery packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Moisture causes damage electronics. Avoid water exposure to all equipment not specially
designed and protected for this purpose.
• Never lick or place any portion of your model in your mouth as it could cause serious injury
or even death.
WARNING
SAFETY PRECAUTIONS AND WARNINGS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Outlaw and is the answer not in the manual?

Questions and answers

Summary of Contents for Staufenbiel Outlaw

  • Page 1 Do not use with incompatible compo- nents or alter this product in any way outside of the instructions provided by Gustav Staufenbiel GmbH. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
  • Page 2: Specifications

    SPECIFICATIONS SPECIFICATIONS 1200 mm (47 in) 1315 mm (52 in) 64,0 dm² (992.0 in²) 1600 - 2000 g (56 - 70 oz) ACCESSORIES PNP-VERSION ARF-VERSION Built-in: Needed: GTX-3546 (760KV) GTX-3546 (760KV) (4x) DS 3510 MG (4x) DS 3510 MG 14x7“ APC E 13x6,5“...
  • Page 3 The Outlaw is an pure Aerobtatic and 3D Biplane in a high quality Plywood and Balsa construc- tion. The Outlaw is available in PNP and ARF Version. Some steps in this manual are done in the PNP Version and only needs to be finsihed in ARF Version. Tese steps are marked with -ONLY-ARF- Version.
  • Page 4 Install the wheels and the wheel shoes as shown on the pictures. Install the wheelshoes with the bracket on the main gear rod. ARF VERSION ONLY: Install the backmount motor mount on the Dy- mond GTX3546 and use Loctite to fasten the screws.
  • Page 5 Connect the Dymond Smart 60 Esc to the motor. Check the direction and switch in case of wrong direction two of three motor cables. Secure the ESC and cable with velcro and fastener. Install the cowling. Install the spinner and propeller. We recom- mend to balance the propeller to reduce vib- rations.
  • Page 6 Slide the elevator from the back in the fuse- lage and align them correct. Mark the glued areas with a felt tipped pen and remove the cover. Align the evelvator exactly and glue it with thin CA. We recommend using an appli- cator for the CA.
  • Page 7 Sand the rudderhorn slightly and glue them as shown on the picture with 5 min epoxy. Insert the tailskid into the fuselage and bolt it. ARF VERSION ONLY: Extend the elevator servocable with an 50cm extension. Use e commercial fastener ore tape to secure the connector.
  • Page 8 Assembly the elevator linkage. Adjust the length for the fist step to 145mm. The fine adjustment should be done with neutral servohorn and neutral rudder. Install the rod end to the servo horn of the rud- derservo. Use Loctite. ARF VERSION ONLY: Set the servo with the transmitter to neutral and install the servohorn.
  • Page 9 Route the assembled cable from the back into the fuselage. Install the cable. Please take care that the cables are not twisted in the fuselage. Turn the eyelits to light tension. Please loosen after adusting the connection to derotate the cable.
  • Page 10 Remove the covering at the battery hatch to create an air exhaust. RECEIVER Use velcro to fasten the receiver in front of the rudder servo. Fix the battery with velcro und safe it with an additional velcro loop. Open and close of the battery hatch with the quick fastener.
  • Page 11 THE WINGS Sand the rudderhorn and glue it with 5 min epoxy. Install the ball link and safe it with 5 min epoxy. ARF VERSION ONLY: Route the aileron servo cable through the wing and install the servo. Use Loctite. Assembly the elevator linkage.
  • Page 12 Install the pivot ball at the trailing edge for the aileron linkage. Use 5 Min epoxy Assembly the elevator linkage. Adjust the length for the first step to 250mm. The fine adjustment should be done with neutral servo- horn and neutral rudder. Prepare all parts for the wing asembly.
  • Page 13 Insert the wing joiner into the fuselage and mount the lower wing. Install the upper wing and fasten it in following order. (Screw-Shimring-Strut-Nut) The arrow must show up. Install the rudder linkage and adjust it as in the steps described before.
  • Page 14: Control Throws

    40% - 60% Expo to all control surfaces THE END Now have some fun with the first flight of you new OUTLAW. If you done all setting as written here in the manual you will have a fantastic and precise flying...
