Delta Electronics 10GBASE-SR SFP+ Optical Transceiver LCP-10G3A4EDR Specification Sheet page 3

Optical Transmitter Characteristics (T
Parameter
Data Rate
Signaling speed variation from
nominal.
Average Output Power
Wavelength
Spectral Width RMS
Transmitter OFF Output Power
Extinction Ratio
Optical Modulation Amplitude
Relative Intensity Noise
Optical Return Loss
Transmitter eye mask definition
{X1, X2, X3, Y1, Y2, Y3}
DELTA ELECTRONICS, INC.
℃
= -5 to 70 )
C
Symbol Min. Typ.
R 10.3125
P -5
avg
λ 840
P
off
ER 3
Compliant with Minimum
OMA
OMA relation table
RIN
ORL
{0.25, 0.40, 0.45, 0.25, 0.28, 0.40}
Transmitter eye mask definition
3
LCP-10G3A4EDR
℃
Max. Unit
Gb/s
±100 ppm
-1.8 dBm
860 nm
0.45 nm
-30 dBm
dBm
-128 dB/Hz
12 dB
www.deltaww.com
Note
Revision: 0B
2008/9/5
