Configuration
1. In the Network / WiFi menu, press the
Add button [
2. Enter the name for the extended WiFi
in the ESSID field [
>
The mode must be set as Access
Point .
3. Select the WiFi Encryption tab. Select
the button on the right next to the
password field to display the pre-set
password [ Figure
the password in a secure place. Con-
firm the entries with the Save button.
>
A new network appears in the WiFi
overview [
4. Confirm with the Save & Apply button.
5. Test the connection. Disconnect the
Ethernet cable and connect the laptop
with the new WiFi. Enter the SSID and
the password noted down in the pre-
vious step.
>
A website can be opened.
6. Connect the Ethernet cable in the
combi-steamer.
7. Close the electrical compartment.
>>
The generated WiFi can be used by
other WiFi adapters and combi-
steamers in WiFi client mode. For this,
the configuration must be carried out
with the created SSID and the noted
password.
8 / 32
Figure 17].
Figure 18].
19]. Note down
Figure 20].
80.51.858_iCombiPro-iCombiClassic-SCC_WiFi-Adapter_IM_US-

4.2.3 Changing the IP address

NOTE
Connection test fails despite adequate
signal strength
If the WiFi adapter has the same IP
address as the access point, the
connection test will fail despite good
signal strength and correct
configuration settings of the WiFi
network.
Remove the IP address conflict:
Check the IP address set on the
n
access point.
Change the IP address set on the
n
WiFi adapter.
1. Log in to the menu.
2. Set a different IP address in the main
menu under Menu – System – LAN IP
address .
3. Follow the instructions on the screen.
>
Use the newly set IP address to ac-
cess the web interface of the WiFi
adapter.
>>
Repeat the connection test.

4.2.4 Testing the WiFi adapter

NOTE
Test the connection of the WiFi
adapter. If incorrect settings have been
made, the settings must be adapted or
the WiFi adapter must be reset.
Use the magnet (Reed contact) to
n
reset the WiFi adapter.
