Altronix NetWay112 Series Installation Manual page 3

Fig. 2 - PoE/PoE+ Camera Deployment.
Netway112X
Power
Input
Fig. 3 - Extending Data Range utilizing NetWayXTX Extender (refer to NetWayXTX Installation Instructions).
Netway112X
Power
Input
Network Switch
Fig. 4 - Powering 12VDC IP Camera utilizing NetWay3012 Adapter
(refer to NetWay3012 Installation Instructions)
Netway112X
Power
Input
Network Switch
Fig. 5 - IP Access Control Deployment
Netway112X
Power
Input
Network Switch
NetWay112X Installation Guide
Typical Applications:
Network Switch
Port shutdown
input
up to 100m
Port shutdown
input
up to 100m
Port shutdown
input
Port shutdown
input
up to 100m
NetwayXTX
Netway3012
up to 100m
PoE/PoE+ Camera
Additional 100m
Card
Reader
HID
Solo Edge
Device
PoE/PoE+ Camera
12VDC Camera
Electric
Strike
- 3 -
