Washing machine rack WP-3 with two drawers
Assembly components:
Side panel - 2 pcs
1
Top shelf - 1 pcs
2
Top drawer - 1 pcs
3
Bottom drawer - 1 pcs
4
Spacer - 2 pcs
5
Leg clamp - 4 pcs
6
Rubber feet -
Leg M10 x
8
7
4 pcs
30 - 4 pcs
3
4
Assembly Guide
Hex key 2,5 - 1 pcs
Fixing kit for
13
9
wall- 4 pcs
6
WP-3
Hex key 4 - 1 pcs
Screw M4 x 8
Screw M6 x 10
10
11
- 26 pcs
Nut M6 -
Nut M10 -
14
34 pcs
4 pcs
2
5
Wrench 10 - 1 pcs
Screw M6 x 12
12
- 34 pcs
- 4 pcs
Washer
Hexagonal
15
16
coupling cap
M6 - 4 pcs
- 10 pcs
1
8
Advertisement
Related Manuals for MN Mounting Solutions WP-3
Summary of Contents for MN Mounting Solutions WP-3
- Page 1 Assembly Guide WP-3 Washing machine rack WP-3 with two drawers Assembly components: Side panel - 2 pcs Top shelf - 1 pcs Top drawer - 1 pcs Hex key 2,5 - 1 pcs Hex key 4 - 1 pcs Wrench 10 - 1 pcs...
- Page 2 Assembly Guide WP-3 Assembly Instructions: 1. Start by unpacking Rack WP-3. From the left Side Panel , remove the side panels rails from the . They must be extended to the maximum, as shown in the picture. Press the lever on the rail and at the same time remove the top drawer panel. Do the same with the bottom panel.
- Page 3 Assembly Guide WP-3 2. Screw both Spacers to the Side Panels with screws and nuts 3. Install the Top shelf and fasten with screws and nuts . Put on the nuts Hexagonal coupling cap...
- Page 4 Assembly Guide WP-3 4. Place the Rack WP-3 on the legs: screw the nut onto the leg screw it in as shown in the picture. 4a. Or place the Rack WP-3 on the Install all 4 legs. Level the Rack WP-3.
- Page 5 6. After installing the legs or feet , measure the distance from the bottom hole of the Rack WP-3 to the floor. Install wall dowels into the wall as picture to secure the Rack WP-3 under the washing machine. 7. Insert the screws...
- Page 6 Assembly Guide WP-3 8. Place the washing machine on the Rack WP-3, press the legs of the machine with the Leg clamps and tighten them. Assembly of drawers 9. Screw the sides of the Top drawer as shown with the screws...
- Page 7 Assembly Guide WP-3 10. Turn the frame of the Top drawer over and install the bottom as shown in the picture. Tighten the screws 11. Screw the sides of the Bottom drawer as shown with the screws...
- Page 8 12. Turn the frame of the Bottom drawer over and install the bottom as shown in the picture. Tighten the screws 13. Install Top drawer and Bottom drawer on the rails in the Rack WP-3. Your Rack WP-3 is set up and ready.
