MN Mounting Solutions WRM Series Installation Manual

Download this manual

Installation Guide for WRM-series

Wall Mounting Systems

WRM-250

SAFETY INSTRUCTIONS

1. Only entrust loudspeaker mounting equipment to experienced professionals. Also strictly follow the provided safety instructions.

Improperly installed mounting equipment may result in property damage, personal injury and/or liability for the installing

contractor.

2. Always use safety cables! This will prevent equipment from falling during/after setup and while exploiting.

3. Always check if the wall surface is structurally strong enough to support load. Make sure the wall and/or ceiling structure allows

to hold the weight of the speaker including its bracket.

4. Only use appropriate fasteners.

5. Always make sure to securely use and tighten/lock all mounting bolts provided. Loose bolts may become unscrewed over time

due to vibration which could potentially create a safety hazard when not tightened securely.

www.mnmounting.com

info@mnmounting.com

2 Merezhna str., Bila Tserkva,

Kyiv region, 09100, Ukraine

Installation Guide

WRM - series

Models:

WRM-300

Need help?

Do you have a question about the WRM Series and is the answer not in the manual?

Page 1 Installation Guide WRM - series Installation Guide for WRM-series Wall Mounting Systems Models: WRM-250 WRM-300 SAFETY INSTRUCTIONS 1. Only entrust loudspeaker mounting equipment to experienced professionals. Also strictly follow the provided safety instructions. Improperly installed mounting equipment may result in property damage, personal injury and/or liability for the installing contractor.
Page 2 Installation Guide WRM - series Installation Instructions: 1. First, release the upper bolt which securing the speaker plate to the 2. Screw the speaker plate to the rear bracket arm. Now remove the speaker (4) holes of the loudspeaker by using all plate from the arm.
Page 3 Installation Guide WRM - series 5. Press down on the top of the loudspeaker until it stops and then 4. Slide the speaker plate along with tighten the upper bolt of the speaker the loudspeaker onto the lower bolt of plate.

Wrm-250Wrm-300
