MN Mounting Solutions SR-600 Series Assembly Manual

Sound rack

Assembly Guide for Sound Racks

Models:

SR-600/12U

SR-600/24U

SR-600/36U

SAFETY INSTRUCTIONS

1. Entrust mounting equipment only to experienced professionals and strictly follow the providedv safety instructions. Improperly

installed equipment may result in property damage, personal injury and/or liability for the installing contractor.

2. Only use appropriate fastening hardware.

3. Always make sure to securely use and lock all mounting bolts. Loose bolts may become unscrewed over time due to vibration

which will then create a safety hazard.

www.mnmounting.com

info@mnmounting.com

2 Merezhna str., Bila Tserkva,

Kyiv region, 09100, Ukraine

Assembly Guide

SR-600 series

Table of Contents

Do you have a question about the SR-600 Series and is the answer not in the manual?

Page 1 Assembly Guide SR-600 series Assembly Guide for Sound Racks Models: SR-600/12U SR-600/24U SR-600/36U SAFETY INSTRUCTIONS 1. Entrust mounting equipment only to experienced professionals and strictly follow the providedv safety instructions. Improperly installed equipment may result in property damage, personal injury and/or liability for the installing contractor.
Page 2 Assembly Guide SR-600 series Assembly components: Top / bottom frame - 2 pcs Pillar - 4 pcs Side door - 2 pcs Adjustable leg - 4 pcs Screw M6x16 DIN912- 16 pcs www.mnmounting.com info@mnmounting.com 2 Merezhna str., Bila Tserkva, Kyiv region, 09100, Ukraine...
Page 3 Assembly Guide SR-600 series Assembly Instructions: 1.1. Optional!!! Install a Wheels Set 50 1. Start the assembly by installing instead of legs. legs ( )into frame ( 3. Install the other frame ( ) onto 2. Install pillars ( ) in the frame (...
Page 4 Assembly Guide SR-600 series 4. Tighten the screws ( ) of all pillars ( 5. Install side covers ( www.mnmounting.com info@mnmounting.com 2 Merezhna str., Bila Tserkva, Kyiv region, 09100, Ukraine...
