- Page 1 The World’s Most Advanced Massage Chairs ® User Manual Nokori M980 Massage Chair ® yner...
- Page 2 Your Chair External Structure Speaker Neck Pillow Air Ionizer Chromatherapy LED Lights (located on right speaker) Wireless Charging Pad Back Cover Back Cushion USB Port Quick Access Control Panel Tablet Remote Control Arm Panel Seat Cushion Legrest Power Box Caster Footrest...
- Page 3 Welcome to Thank you, and congratulations on purchasing your very own Kyota Massage Chair product - you’ve made a great buying decision. Welcome to the Kyota family. Please review the entire manual, including all safety information, before assembling or using your chair. If you are assembling the chair yourself, please see the Assembly Guide next and reference the online assembly video.
- Page 4 Chair Features Syner-D Back Massage Mechanism ® Flex-D Massage Track Tablet Remote Intelligent Voice Command + Control Complete Calf Kneading + Oscillation Wireless Charging Pad USB Charging Station Weightless Zero Gravity Recline Chromatherapy Programs Premium Bluetooth Speakers SootheMe Sound Therapy Quick Access Control Panel Zero Wall Fit Space-saving Technology...
-
Page 5: Table Of Contents
Table of Contents Preparation Time Remaining SootheMe™ Sound Therapy Installation Site Volume Level Clearance Space for the Chair Quick Access Panel + Joystick Control Floor Protection Intelligent Voice Command + Control Move Methods Turn Off Listening Connect to Power Turn On Listening Chair Setup Activating Voice Control Main Power Switch... -
Page 6: Preparation
Preparation Installation Site Clearance Space for the Chair - 4” clearance for the recline of the backrest; 24” clearance for the extension of footrest and sliding forward of the chair. - Keep it 3 feet away from the TV, radio or other audio & video appliance to avoid signal interference. -
Page 7: Move Methods
Move Methods Apply pressure to the back of the massage chair from behind to pivot on the Castors. Have a second person up front to guide the Footrest until in the correct position. Maintain clearances as mentioned above. Gently lower into place. Do not pull on the side arms. - Do not move the chair when there is user inside. -
Page 8: Chair Setup
Chair Setup Getting Comfortable Main Power Switch To power up the chair, flip the main power switch located on the back of the base of the chair to ON. Ensure the electrical cord is connected to a 110V grounded outlet and plugged into the power cord port located on the back of the base of the chair. -
Page 9: Getting Out Of The Chair
Truefit Body Scanning Massage program will start after countdown timer Getting Out of The Chair To easily exit the chair at any time, tap the POWER button on the top right of the home display, on the Tablet Remote to restore the chair to the upright position. -
Page 10: Tablet Remote Layout
Chair Setup Tablet Remote Layout... -
Page 11: Tablet Remote Operation
Tablet Remote Operation 1. Home Page – After turning on your chair, this is the first screen you will see on your Tablet Remote. Use this screen to navigate all menu options. To select, simply tap the screen with your finger. 2. -
Page 12: Getting Started
Getting Started Auto Programs From the home display, tap the AUTO button to enter Auto Program Menu. Choose from Flex, Stretch, Gentle, Deep Breathe, Energize, Rest & Recover, Upper Body, Neck & Spine, Lower Body, Tension Release, Full Body or Demo. To enter the program you desire tap the screen. -
Page 13: Auto Program Descriptions
What For? Program Description Targeted airbag compression provides a full body stretch Soothe muscles after sports Flex while the double back-mechanism performs a combination of massage techniques to help awaken and ignite your muscles for the day ahead. Great for a quick midday break A revitalising massage that is ideal for a mid-day boost. -
Page 14: Personalize Experience
Personalize Experience Custom Selections from Auto Programs To personalize your massage to your exact needs, swipe left on the Tablet Remote from the In-Use Screen to be taken to the Custom Selections screen. The Custom Selections screen can be used to tailor your massage exactly to your needs. Here you will have complete control over the duration, airbag settings/Intensity, foot rollers, and back/leg heat. -
Page 15: Maximum 4D Level
Maximum 4D Level Use this control to increase or decrease the maximum intensity of the 4D back mechanism that works the back and shoulder regions. All auto massages are pre-programmed to have varying 4D intensity, this setting will set the upper limit of these fluctuations . 1 = light, 5 = firm, or Off. Tap screen to select setting. -
Page 16: Adjustments
Personalize Experience Adjustments Tap Adjustments to enter the Adjustments display screen. While your massage program is running, use this screen to make adjustments to lighting, chair angles, or time. To return to the In-use screen, simply swipe right or tap the arrow on the Tablet Remote screen, which will take you to the home page, and then tap ‘massage running screen’... -
Page 17: Led Brightness
LED Brightness Select your desired light brightness: 1 = dim, 2, 3, 4, 5 = bright. Tap screen to select desired brightness setting. Note: You may only choose light color in solid and multi-rotate themes. Calf Rollers & Oscillation Toggles on/off Calf Rollers & Oscillation feature. Rollers combine with oscillating movement and compression air cells to simulate hands gently relieving tension and pain in the calf region of each leg. -
Page 18: Sootheme™ Sound Therapy
Personalize Experience Sounds Tap Sound on the home display to enter the Sound display screen. Use this screen to select and control the SootheMe™ Sound Therapy feature of your chair. The selected sound will play from the speakers next to your head. To turn SootheMe™ Nature Sounds off, de-select the activated sound. -
Page 19: Quick Access Panel + Joystick Control
Quick Access Panel + Joystick Control The Quick Access Panel + Joystick Control allows you to turn the chair on and off, control chair angles, turn on lights and sounds, adjust volume, pause your massage, select auto program’s, and set and select your favorite massage programs. Favorite Auto Zero Volume... -
Page 20: Intelligent Voice Command + Control
Personalize Experience Intelligent Voice Command + Control Turn Off Listening Commands Say Phrase You can turn off intelligent voice control “Activate Voice Control” listening by using the tablet remote. Tap System from Home display, then toggle Voice Then speak one of the following Commands Control to Off. -
Page 21: Mymassage™ Memory Programs
MyMassage Memory Programs ™ Your chair has the ability to save your favorite customized massage programs to memory. To create a custom MyMemory program, you first need to set up the chair for what it is you want to record. To do this, use Manual Settings to create a manual massage program with all of your desired air, heat, speed, and intensity settings. -
Page 22: Settings
Settings System Tap System on the home display to enter the system display screen. Use this screen to adjust and personalize your chair and Tablet Remote settings. Swipe up to see the additional settings not visible on the screen, swipe down to go back to the top. Tap System button Sleep Mode Toggle your desired sleep mode setting: On or Off. -
Page 23: Bluetooth
Indicates the latest software installed on your device. Help Tap Help to be taken through to the help screen. Here you will be able to access where to find help and contact information if you are having any troubles with your Nokori M980 Massage Chair. -
Page 24: Create A Massage
Create a Massage Manual Settings Have a particular spot that needs more work? Take the power of massage into your own hands with Manual Settings. Tap Manual Settings on the home display to enter the Manual Settings display screen. Use this screen to fully customize your own massage and find the perfect treatment for you. -
Page 25: Focus Zone
Focus Zone Controls the range of motion of the back mechanism, Whole travels the entire length of the track, Partial travels a short distance and reverses direction for focused relief, Point stops on the track for targeted relief. Tap screen to select setting. Adjust: Partial and Point location can be fine tuned by using the Adjust setting. -
Page 26: Staying Safe
Staying Safe Safety Information To ensure safe use of the massage chair and avoid injury or unsafe conditions, please read and follow all instructions before using product. WARNING USE NOT RECOMMENDED FOR CERTAIN PERSONS Use of massage chair may not be safe or suitable for persons with certain medical conditions and could cause serious injury or death in some circumstances. - Page 27 CAUTION To avoid the risk of minor injury or discomfort, or damage to the massage chair or other property, please read and follow these instructions for safe use of massage chair: - Do not stand or stack heavy objects on footrest. - Do not operate heating features of chair while under a blanket or pillow.
- Page 28 Staying Safe - To avoid damage to chair or floors, do not drag or push the chair or roll its casters on wood floor or carpet. See instructions on p.6 for safely moving chair. - If massage chair is not working properly, has been dropped or damaged, or has been dropped into water or exposed to flooding, return the appliance to a service center for examination and repair before attempting to use.
-
Page 29: Fixing Issues
The air hose is blocked Straight the air hose and clear out the blockage Specifications Model Nokori M980 Dimension of Main Body (in) 63 x 32 x 50 (L x W X H) Necessary Clearance to Wall (in) 4” Net Weight (lbs) Shipping Weight (lbs) Max. -
Page 30: Frequently Asked Questions
5 minutes then plug back in and power back up to see if it self-healed. If you are still having an issue, give Kyota a call at 800-242-0761. Q: I can never seem to get in my Kyota Massage chair, someone is always in it. - Page 32 The World’s Most Advanced Massage Chairs ® 72 Stard Road, Seabrook, NH 03874 Toll Free #: (800) 242-0761 www.kyotamassagechairs.com Version 1.2...
