Related Manuals for KYOTA Kokoro M888 4D
Summary of Contents for KYOTA Kokoro M888 4D
- Page 1 The World’s Most Advanced Massage Chairs ® User Manual Kokoro M888 4D Massage Chair...
- Page 3 Welcome to Thank you, and congratulations on purchasing your very own Kyota Massage Chair product, you’ve made a great buying decision. Welcome to the Kyota family. Inside this manual, you will find everything you need to setup and safely enjoy your chair.
- Page 5 Your Chair External Structure Ionizer Speakers Shoulder Airbag Voice Control Mic Quick Access Control Panel Pillow Cushion Chromotherapy Light Back Cushion Arm Panel USB Port Seat Cushion Chromotherapy Light Legrest Castor Footrest Remote Control Auto- Renew 20 min Speed: Width: Power Button Intensit Emergency Stop...
- Page 6 Chair Features 4D Back Massage Mechanism J-Track Massage Intelligent Voice Command + Control Tri-zone Deep Penetrating Heat Truefit™ Body Scanning Zero Wall Fit™ Space-Saving Technology 12 Auto Programs USB Charging Station Customizable Massage Integrated Air Ionizer Complete Calf™ Kneading + Oscillation TrueFit™...
-
Page 7: Table Of Contents
Table of Contents Preparation Getting Started Airbag Massage Installation Site Airbag Region Clearance Space for the Chair Airbag Intensity Floor Protection All Airbags Off Move Methods Foot Reflexology Rollers Connect to Power Heating Chair Setup Integrated Air Ionizer Main Power Switch Settings Adjust Pillow Setting Tool... -
Page 8: Preparation
Preparation Installation Site Clearance Space for the Chair - 4” clearance for the recline of the backrest; 20” clearance for the extension of footrest and sliding forward of the chair. - Keep it 3 feet away from the TV, radio or other audio & video appliance to avoid signal interference 4”... -
Page 9: Move Methods
Move Methods - Apply pressure to the back of the massage chair from behind to pivot on the Castors. Have a second person up front to guide the Footrest until in the correct position. Maintain clearances as mentioned above. Gently lower into place. Do not pull on the side arms. Castors - Do not move the chair when there is user inside. -
Page 10: Chair Setup
Chair Setup Getting Comfortable Main Power Switch To power up the chair, flip up the main power switch located on the back of the base of the chair to ON. Main power switch Power cord input - To avoid possible damage to product or injury to unsupervised children, always turn off power switch and unplug massage chair from electrical outlet immediately after use. -
Page 11: Connecting The Wireless Remote Control To Bluetooth
Connecting the Wireless Remote Control to Bluetooth Before you pair your wireless remote control with the massage chair, make sure the chair is powered on. To power on the chair without your wireless remote, press the ON/OFF button on the quick access control panel located on the top of the right arm panel. To pair your wireless remote control, simultaneously hold down the MENU and OK buttons for 4 seconds. -
Page 12: Quick Access Control Panel
H1 - Headline of Page Chair Setup Quick Access Control Panel Another feature of your chair is a built in quick access control panel. The quick access control panel is located on the top of the right arm panel. This control panel allows you to turn your chair ON/OFF, emergency shutoff the chair, cycle through 4 Auto programs, adjust the legrest and backrest, or toggle through zero gravity positions. -
Page 13: Truefit™ Body Scanning
Truefit™ Body Scanning Navigate to any auto program and press the OK button. The chair will automatically begin scanning your body, mapping your back, shoulders, and neck. During this process it is important to remain seated back into the chair without lifting your head. -
Page 14: Auto Programs
Auto Programs Auto Programs (AUTO) Programs When the massage chair is Menu Health operating, press the AUTO Auto Health Pain relief Manual button on the remote control Stretch Airbag to enter the Auto Program Music sync Pain Relief Roller Experience menu display. - Page 15 What for? Description This program is the best choice to relax Comprehensive massage session using deep tissue tired muscles and increase physical vigor. kneading, and tapping. This is a great program for people who The most intense of the massage programs. This strong work at a desk or travel a lot.
-
Page 16: Create A Massage
Create a Massage Manual Programs Press MENU button on remote control. Select Menu Auto Mode Manual from Menu display, then use up or down Position Manual buttons to navigate among: Mode, Position, Width Airbag Width, Speed, 4D, and Footrest. Speed Roller Heating Footrest... -
Page 17: Massage Width
Massage Width Navigate to Width, press right button, then use Menu Menu the up or down button to select your desired Auto Mode Auto Narrow Position Middle Manual Manual roller width: Narrow, Middle, or Wide. Press Width Wide Airbag Airbag OK button to select width. -
Page 18: Getting Started
Getting Started Airbag Massage Press MENU button on remote control. Select Menu Airbag from Menu display, press up or down Auto Position Intensity Manual button to navigate among: Position, Intensity, All Off Airbag and All Off. Roller Heating Timer Settings Stop Select by the navigation keys Airbag Region... -
Page 19: Foot Reflexology Rollers
Total Sole Foot Reflexology Rollers Press MENU button on remote control. Select Roller from Menu Menu display, then use the up or down button to navigate Auto Quick Soft Manual among: Quick, Soft, and Stop. Press OK button to select the Stop Airbag speed level you desire. -
Page 20: Settings
Your massage chair includes Bluetooth compatibility so you can play and enjoy your favorite music. To connect your Bluetooth enabled audio device, go into your audio device settings, navigate to Bluetooth settings and pair with the device named Kyota M888#######. -
Page 21: Intelligent Voice Command + Control
Intelligent Voice Command + Control Your chair comes with built in intelligent voice control. This feature allows you to control your chair and massage experience completely hands-free by using one of the many voice commands. To activate the intelligent voice control function, simply say “Turn on speech recognition mode”. -
Page 22: Staying Safe
Staying Safe Safety Information To ensure safe use of the massage chair and avoid injury or unsafe conditions, please read and follow all instructions before using product. WARNING USE NOT RECOMMENDED FOR CERTAIN PERSONS Use of massage chair may not be safe or suitable for persons with certain medical conditions and could cause serious injury or death in some circumstances. - Page 23 CAUTION To avoid the risk of minor injury or discomfort, or damage to the massage chair or other property, please read and follow these instructions for safe use of massage chair: - Do not stand or stack heavy objects on footrest. - Do not operate heating features of chair while under a blanket or pillow.
- Page 24 H1 - Headline of Page Staying Safe - To avoid damage to chair or floors, do not drag or push the chair or roll its casters on wood floor or carpet. See instructions on p.6 for safely moving chair. - If massage chair is not working properly, has been dropped or damaged, or has been dropped into water or exposed to flooding, return the appliance to a service center for examination and repair before attempting to use.
-
Page 25: Fixing Issues
Fixing Issues Trouble Shooting Symptoms Possible Causes Possible Solution Noise is heard These noises are normal and arise No need to take any measures while in use from friction between the massage rollers and the leather cover Massage Chair The power cord is not secured Insert the power plug properly into the does not start into the socket... -
Page 26: Frequently Asked Question
Q: My chair is not performing as expected. What should I do? A: Your Kyota massage chair is an amazing combination of programming and robotics. On occasion the chair just may need to be rebooted. To do this power down the chair and unplug from the wall for 5 minutes then plug back in and power back up to see if it self-healed. - Page 28 The World’s Most Advanced Massage Chairs ® 72 Stard Road, Seabrook, NH 03874 Toll Free #: (800) 242-0761 www.kyotamassagechairs.com Version 2.4...
