- Page 1 ASSEMBLY INSTRUCTIONS : PREVAIL SIDE CHAIR Description : C-59 Item No. ITEM NO.: C-59 Printed in Vietnam ISSUED AUG 26, 2020 - 1 -...
-
Page 2: Before Assembly
Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws, bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: C-59 Printed in Vietnam ISSUED AUG 26, 2020 - 2 -... -
Page 3: Part List
(M6 x 80mm) (M4 x 50mm) Short Screw L-bracket (M3.5 x 15mm) Lock Washer Flat Washer (6.5 x11mm) (6.5 x19mm) Allen Key (M4 x 30mm x 110mm) ITEM NO.: C-59 Printed in Vietnam ISSUED AUG 26, 2020 - 3 -... - Page 4 Attach middle stretcher (F) to side stretchers (E) with screws (5). Then attach side stretchers (E) to front and back legs with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: C-59 Printed in Vietnam ISSUED AUG 26, 2020...
- Page 5 STEP 3 Attach seat (C) to top of seat frame (B) with brackets (6) and screws (5) as shown below. Tighten with a screw driver. ITEM NO.: C-59 Printed in Vietnam ISSUED AUG 26, 2020 - 5 -...
