CONVERSION FOR MAIZE HARVESTING
For maize harvesting, the combine can be tted with a 3- or 4-row maize header. Some other modi cations are
also required to make the combine suitable for maize harvesting.
The instructions are based on a combine equipped with the following components:
HD front axle with oil bath type nal drives
Table lifting mechanism tted with hydraulic rams dia 50 mm
HD table drive
400...1150 RPM (slow speed) cylinder drive variator
8-rasp-bar HD threshing cylinder
Wide-spaced HD concave
HD straw walkers
Optional HD straw chopper
The copper drive equipped with the changeable chopper drive pulley
M1
Remove the cutting table from the feeder elevator and replace it with the maize header.
remove the belt guard (43 g.M2) and belt (48 g. M2) of the table clutch
remove the table lifting rams from the feeder elevator NOTE! Remove the pressure before disconnecting.
release the hydraulic hose and electric wire by removing the guard plate (75 g. M1) from the right side of
the feeder elevator
remove the stubble height indicator from the cab
place a suf ciently strong support beneath the feeder elevator
Remove the bearing blocks (14 g. M1) and drive the combine slowly backwards in order to table feed ele-
vator being separeted from combine.
Remove the belt guard (53 g. M1) and pulley (39 g. M2)
